Поз.
Артикул
Описание
126
RUBBER SPRING SPRING STOP TO FRAME BOTTOM SIDE
129
LOCK RUBBER SPRING TO BRACKET
132
WASHER
144
BRACKET RUBBER SPRING
147
SCREW MOUNTING TO CONSOLE M 14X35
147
SCREW , Replaced By: N308676014008
150
WASHER , Replaced By: N000125015019
150
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
153
NUT STEERING SUPPORT TO FRAME
153
NUT , Replaced By: N910113014000
168
RUBBER MOUNTING , Replaced By: A3853300075
168
RUBBER MOUNTING AXLE STOP
171
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
174
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
177
NUT STRAP TO BRACKET
177
NUT , Replaced By: N910113010000
339
SHOCK ABSORBER , Replaced By: A0043237100
339
SHOCK ABSORBER , Replaced By: A0043233300
339
SHOCK ABSORBER FRONT AXLE, ONLY REPLACEABLE BY PAIRS
339
SHOCK ABSORBER FRONT AXLE, ONLY REPLACEABLE BY PAIRS
342
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
342
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
342
RUBBER BUFFER , Replaced By: A0003232885
342
RUBBER BUFFER , Replaced By: A0003233144
345
SPACER TUBE , Replaced By: A0003232550
345
BUSHING , Replaced By: A0003233150
345
SPACER RINGTO 002 323 86 00,003 323 03 00,
345
BUSHINGTO 004 323 52 00
357
CONSOLE RIGHT SHOCK ABSORBER
357
CONSOLE LEFT SHOCK ABSORBER
357
CONSOLE , Replaced By: A3833200478
357
CONSOLE , Replaced By: A3833200578
357
CONSOLE , Replaced By: A3853200678
360
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
363
WASHER , Replaced By: N007349013005
363
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
369
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
369
SCREW , Replaced By: N308676012012
372
NUT SUPPORT TO SIDE MEMBER
378
SCREW SHOCK ABSORBER TO TOP BRACKET
381
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
381
NUT COMBINATION CYLINDER TO BEARING BRACKET
399
SCREW RUBBER MOUNTING TO SUPPORTING ARM M16X80,5 566418
408
LOCK PLATE SHOCK ABSORBER TO LOWER BEARING BRACKET,4 336573
999
SHOCK ABSORBER , Replaced By: A3853260200
999
SHOCK ABSORBER , Replaced By: A3853260200
999
SHIM
