Поз.
Артикул
Описание
10
CIRCULATION PUMP
10
CIRCULATION PUMP , A 06254720120629
30
CLAMP14 MM
40
HOSE FROM RECIRCULATING PUMP TO HEAT EXCHANGER
50
CLAMP14 MM
70
BRACKET FASTENING, HOSES
100
CLAMP14 MM
110
LINE FROM HEAT EXCHANGER TO DISTRIBUTOR
120
CLAMP14 MM
140
BRACKET REGENERATION LINE
150
HOSE FEED TO HEAT EXCHANGER
150
HOSE ASSEMBLY FEED TO HEAT EXCHANGER, A 03708020111124
150
HOSE FEED TO HEAT EXCHANGER
150
HOSE LINE FEED TO HEAT EXCHANGER, A 03276820111022
150
HOSE LINE FEED TO HEAT EXCHANGER
160
CLAMP25 MM
180
HOSE ASSEMBLY FROM ENGINE TO FEED LINE, A 08330620130117
180
HOSE ASSEMBLY FROM ENGINE TO FEED LINE, A 08330520130117
250
HOSE ASSEMBLY RETURN
250
LINE RETURN
250
HOSE ASSEMBLY RETURN, A 06254620120629803
255
CLAMP25 MM
260
SCREW SCREENING PLATE TO CYLINDER HEAD COVER M 5X10
270
CLAMP25 MM
280
HOSE ASSEMBLY FROM RETURN LINE TO RECIRCULATING PUMP, A 10549320130731804
280
HOSE ASSEMBLY FROM RETURN LINE TO RECIRCULATING PUMP
280
HOSE ASSEMBLY FROM RETURN LINE TO RECIRCULATING PUMP
280
COOLANT HOSE INDEPENDENT HEATING, A 07056320120910803
280
COOLANT HOSE FROM RETURN LINE TO RECIRCULATING PUMP, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 20130131, Replaced By: A2125017184
290
HOSE ASSEMBLY BETWEEN RECIRCULATING PUMP AND ENGINE
290
HOSE ASSEMBLY BETWEEN RECIRCULATING PUMP AND ENGINE
290
HOSE ASSEMBLY BETWEEN RECIRCULATING PUMP AND ENGINE
295
CLAMP FASTENING COOLANT HOSE
300
CLAMP25 MM
330
HOSE ASSEMBLY BETWEEN RECIRCULATING PUMP AND ENGINE, A 06254620120629
340
CLAMP25-40X13 MM
360
BRACKET FASTENING COOLANT HOSE, A 07056320120910803
400
COOLANT LINE RIGHT, A 10549320130731804
400
COOLANT LINE RIGHT, A 07056320120910803 A 20130608
410
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
900
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
