Поз.
Артикул
Описание
145
FLANGE AT ENGINE, WITH 387.134 ON VEHICLES HAVING NO MERCEDES BENZ CAB UP TO CHASSIS 4 367398
150
GASKET. SEAL DE-AERATION PIPE TO ENGINE
152
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
154
SCREW END PIECE TO EXHAUST PIPE M 10X25
160
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
162
CLAMP FEED LINE TO THERMOSTAT
163
SCREW COVER PLATE TO BRACKET
163
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
163
SCREW , Replaced By: N304017008016
164
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
164
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
164
NUT , Replaced By: N910113006001
164
NUT , Replaced By: N913004008001
170
HOSE FROM FLANGE TO HEATING PIPE
172
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
172
CLAMP , Replaced By: N000000000667
175
LINE , Replaced By: A3875000072
175
LINE HEATING,MOUNTED TOGETHER WITH RADIATOR AT RUBBER BUFFER, 415 5 014668 416 5 000515 417 4 972023
176
SCREW END PIECE TO EXHAUST PIPE M 10X25
179
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
179
CLAMP , Replaced By: N000000000667
185
HOSE , Replaced By: A3635060235
185
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
186
CLAMP25-40X13 MM
186
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
186
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
186
CLAMP , Replaced By: N000000000667
190
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 985 MM,4 635939
190
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1015 MM,4 635938
192
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
193
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
193
CLAMP , Replaced By: N000000000667
200
BREATHER PIPE FROM ENGINE TO EXPANSION TANK,4 635938
202
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
210
BRACKET RADIATOR AND ENGINE BREATHING,AT ENGINE,4 635938
211
BRACKET FUEL LINE TO BELL HOUSING
211
BRACKET , Replaced By: A6454310740
215
NUT , Replaced By: N910113010000
215
NUT STRAP TO BRACKET
220
CLAMP AT BRACKET
220
CLAMP , Replaced By: N916016011202
222
CLAMP , Replaced By: A6739950001
222
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
222
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
222
CLAMP DELIVERY AND SUCTION LINES TO STEERING
230
SCREW COVER PLATE TO BRACKET
230
SCREW , Replaced By: N304017008021
230
SCREW CAB FLOOR COVERING M 6X25
230
SCREW PIPE CLAMP
260
NUT PUMP TO BRACKET
260
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
260
NUT , Replaced By: N913004006001
260
NUT , Replaced By: N913004008001
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
WASHER BRACKET TO RIGHT FENDER, 415 5 014668 416 5 000515 417 4 972023
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET,4 410133
999
BRACKET , Replaced By: A3855010220
999
SUPPORT RADIATOR MOUNTING,4 242404
999
FAN SHROUD , SHORTEN BY 65 MM ON REPALCEMENT DELIVERY UP TO CHASSIS 4 232358, Replaced By: A3835050355
999
SHIM , Replaced By: A3815010295
999
TANK , Replaced By: A3815000749
999
BRACKET , Replaced By: A3815012720
999
HOSE FROM HEATING LINE TO HEATING LINE
999
CLAMP , Replaced By: A3609950601
999
CLAMP , Replaced By: A3609951201
999
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
