Поз.
Артикул
Описание
670
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
670
PLASTIC PIPE RISING PIPE 4X6 MM
671
UNION NUT
672
GLAND , Replaced By: A0019901667
672
SEAL CONE
673
SLEEVE LEAK LINE
725
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
731
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
732
SCREW-IN FITTING LINE CONNECTION
732
FITTING LINE CONNECTION, Replaced By: N000000006446
733
SEAL RING LINE CONNECTION
738
LEVER , Replaced By: A6523200527
741
BALL PIVOT
744
SCREW , Replaced By: N304017008016
744
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
746
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
748
SCREW , Replaced By: N000933008134
748
SCREW FRONT AXLE REGULATING SOLENOID VALVE
751
NUT , Replaced By: N913004008001
751
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
753
VALVE STEERED AXLE SELF-LEVELLING DEVICE
754
REPAIR KIT AIR SPRING VALVE
755
SCREW PLUG , Replaced By: N000908012009
755
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
757
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
759
SEAL RING LINE CONNECTION
761
NUT SUPPORT TO SIDE MEMBER
763
LEVER , Replaced By: A6523200527
765
BALL PIVOT BOTTOM B13X5 MM
767
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
769
SCREW , Replaced By: N304017008016
769
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
771
BRACKET TRAILING AXLE SELF-LEVELLING VALVE
773
SPACER TUBE , Replaced By: A3094310249
773
GUIDE BUSHING TWO-WAY VALVE TO FRAME
775
SCREW , Replaced By: N304017008043
775
SCREW VALVE TO BRACKET M 8X55
777
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
777
NUT , Replaced By: N913004008001
779
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
779
SCREW , Replaced By: A0099900101
779
SCREW , Replaced By: N000933008337
781
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
781
NUT , Replaced By: N913004008001
782
PULL ROD PNEUMATIC SUSPENSION CONTROL
783
YOKE BOTTOM
784
YOKE TOP
785
NUT
785
NUT , Replaced By: N304035008001
786
NUT L.H. THREAD
786
NUT , Replaced By: N304035008002
787
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
787
NUT , Replaced By: N913004008001
791
VALVE TWO-WAY VOSS
791
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
809
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
810
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
811
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
812
HOLLOW SCREW LINE CONNECTION
813
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
814
SEAL RING LINE CONNECTION
817
O-RING CHECK VALVE TO AIR RESERVOIR
822
BRACKET AUTOMATIC LOAD-DEPENDING BRAKE SHUTTLE VALVE, 415 5 014668 416 5 000515 417 4 972023
825
SCREW PIPE CLAMP
825
SCREW , Replaced By: N304017008021
828
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
828
NUT , Replaced By: N913004008001
856
VALVE (CHANGE-OVER VALVE) AUTOMATIC LOAD-DEPENDING BRAKE, 415 5 014668 416 5 000515 417 4 972023
858
VALVE (TEST VALVE), 415 5 014668 416 5 000515 417 4 972023
862
LOCK PLATE AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE, 415 5 014668 416 5 000515 417 4 972023
866
BRACKET AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE
869
RUBBER BUFFER AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE, 415 5 014668 416 5 000515 417 4 972023
872
SCREW BRACKET TO SIDE MEMBER, 815770
876
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
876
NUT , Replaced By: N913004008001
966
VALVE (THROTTLE CHECK VALVE)
969
SEAL RING LINE CONNECTION
972
ADAPTER FITTING RELAY VALVE
999
ROD , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE4 653176, Replaced By: A6173200089, +001N006796016101, +001N913004016004
999
BEARING BRACKET , Replaced By: A6173200089, +001N006796016102, +001N913004016004
999
CONTROL ARM , Replaced By: A6533500106
999
CONSOLE , Replaced By: A6173200078
999
CONSOLE , Replaced By: A6173200178
999
BEARING BRACKET BOTTOM RIGHT,4 336573
999
FITTING , Replaced By: N915039008101
999
BRACKET SENSOR CABLE TO FRONT AXLE
999
SPRING LEAF ,4 669736, Replaced By: A3853203294, +001A3853212912
999
FRONT SPRING ,4 358831 ONLY REPLACEABLE BY PAIRS, Replaced By: A3853202402, +001A3283510025, +001A3523510425
999
SPRING LEAF ,4 669736, Replaced By: A3853203294, +001A3853212912
999
SPRING LEAF , Replaced By: A3853200494
999
SPRING LEAFNO.4
999
SPRING LEAF ,4 669736, Replaced By: A3853212912, +001A3853203294
999
SPRING LEAF
999
SPRING LEAF ,4 669736, Replaced By: A3853212912, +001A3853203294
999
SHACKLE PIN , Replaced By: A3855860332
999
REPAIR KIT , Replaced By: A3855860332
999
REPAIR KIT , Replaced By: A3853200165
999
REPAIR KIT , Replaced By: A3853200128
999
SHEAR BUSHING SHIM TO REAR AXLE
999
ROD PNEUMATIC SUSPENSION CONTROL
999
ROD LEVEL ADJUSTMENT VALVE CONTROL
999
PISTON , Replaced By: A3873200818
999
LINK ,4 707917, Replaced By: A3873231016, +001A3873230385
999
ADHESIVE FOIL GUIDE SIGN
999
PISTON , Replaced By: A3933200718
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3803230160
999
PIN ,4 630534, Replaced By: N000960016247, +001A3853230453, +002N007349017002, +002N913004016005
999
CONTROL ARM , Replaced By: A3933505405
999
CONTROL ARM , Replaced By: A3933505505
999
GUIDE SIGN TRAILING AXLE LIFT
999
ROD , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE4 653176, Replaced By: A6173200089, +001N006796016101, +001N913004016004
999
REPAIR KIT , Replaced By: A3803200028
999
GROMMET LINE PASSAGE AT SIDE MEMBER
999
SCREW , Replaced By: A3529903501
999
REPAIR KIT , Replaced By: A3603200041
999
BRACKET , Replaced By: A3183281840
999
RUBBER BUFFER (RUBBER STOP),EMERGENCY RUNNING,K 017385
999
PIN TORSION BAR TO BEARING BRACKET
999
SPACER
999
SPRING CLAMP , Replaced By: A3123240633
999
SHACKLE FRONT SPRING SUSPENSION,REAR
999
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 31 MM
999
SPRING CLAMP , Replaced By: A6173210333
999
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3094921819
999
BUSHING , Replaced By: A3354310053
999
CLAMP PULL ROD TO AXLE
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
FITTING , Replaced By: A0029905971
999
SEAL RING5X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING4 X 1.50 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING8X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SHOCK ABSORBER , Replaced By: A0043235400
999
FITTING RELAY VALVE,CONNECTION: "40",5 359430
999
FITTING (PARTS KIT),LINE RUPTURE
999
BALLTO 003 429 22 44
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
VALVE (CHECK VALVE)
999
SHOCK ABSORBER , Replaced By: A6233260000
999
SHOCK ABSORBER , Replaced By: A3853260000
999
SHOCK ABSORBER , Replaced By: A0043236600
999
SHOCK ABSORBER , Replaced By: A3853260000
999
FITTING , Replaced By: N915059006000
999
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004342501
999
FITTING PRESSURE REGULATOR,CONNECTION: "40"
999
JOINT BEARING
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 844252, Replaced By: A0034296844
999
SPRING CLAMP , Replaced By: A0003219433
999
PLUG
999
HANDLE
999
HANDLE ,5 292411
999
HANDLE , 415 5 014668 416 5 000515 417 4 972023
999
GROMMET CAB ROOF
999
FITTING , Replaced By: A0039979972
999
FITTING , Replaced By: A0019972572
999
BUSHING , Replaced By: N915062004000
999
BANJO UNION LINE CONNECTIONS
999
BANJO UNION , Replaced By: N915052006003
999
CONNECTOR REPAIR SIZE
999
BANJO UNION , Replaced By: N915052006013
999
HOLLOW SCREW , Replaced By: N915047012100
999
BANJO UNION , Replaced By: N915052004006
999
HOLLOW SCREW , Replaced By: N915047006100
999
HOLLOW SCREW , Replaced By: N915047008100
999
JOINT BEARING , Replaced By: A0009817231
999
JOINT BEARING , Replaced By: A0019814631
999
JOINT BEARING , Replaced By: A0009817331
999
JOINT BEARING , Replaced By: A0009817231
999
SLEEVE , Replaced By: N915062006000
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 957391, Replaced By: A0003200367
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 957391, Replaced By: A0003200267
999
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/73100,K 186867
999
OPERATING PLATE
999
BOOTTO 381 320 07 89,617 320 00 89
999
CUP 3/2-WAY VALVE WABCO
999
REPAIR KIT 3/2-WAY VALVE
999
VALVE BODYTO 002 429 95 44
999
VALVE , Replaced By: A0004291182
999
VALVE , Replaced By: A0004290782
999
GASKETTO 003 429 22 44
999
JOINT (CENTRAL JOINT) TO 658 350 00 05,EHRENREICH
999
JOINT (CENTRAL JOINT) TO 393 350 54 05,LEMFOERDER
999
CONTROL ARM. REPAIR KIT , Replaced By: A0003500305
999
JOINT (CENTRAL JOINT) TO 393 350 55 05,EHRENREICH
999
REPAIR KIT , Replaced By: A0003500213
999
REPAIR KIT. JOINT WITH BALL PIVOT
999
BOOT , Replaced By: A0004631396
999
VALVE , FOR USE WITH MERCEDES-BENZ PLATFORM, Replaced By: A0003290825
999
PROTECTIVE CAP , Replaced By: A0003290092
999
PROTECTIVE CAPTO 000 329 04 25,000 329 08 25,K 186867
999
BOOT ,5 292411
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 320619, Replaced By: A0003283330
999
BOOT
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 957391, Replaced By: A0003280292
999
BOOT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 957391, Replaced By: A0003280292
999
VALVE ,4 809255 CONNECTING LINES TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0003290425, +001A3873200443
999
PROTECTIVE CAP ,4 809255
999
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
