Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE WABCO
5
BRAKE VALVE SERVICE BRAKE KNORR
6
SPRINGTO 345 431 70 05
6
SPRINGTO 345 431 71 05
6
SPRINGTO 345 431 70 05
7
PISTONTO 345 431 71 05
7
PISTONTO 345 431 70 05
8
LOCKTO 345 431 70 05
8
LOCK RINGTO 345 431 71 05
10
LOCK RINGTO 345 431 71 05
11
LOCK RING
12
LOCK RING PLANETARY CARRIER
13
REPAIR KIT LARGE SCOPE TO 345 431 70 05
13
REPAIR KIT , Replaced By: A0014300460
13
REPAIR KIT SMALL SCOPE TO 345 431 70 05
13
REPAIR KIT SMALL SCOPE TO 345 431 71 05
15
GASKET BRAKE SHOE WITH LINING
16
NUT BATTERY CASE
17
SPRING WASHER BRAKE SHOE WITH LINING
18
ROD FROM FITTING TO CLUTCH BOOSTER
19
YOKE
20
NUT FUEL TANK TO SUPPORT
23
HOLLOW SCREW FUEL LINE TO TANK,659794
23
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
24
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
26
SEAL RINGTO 006 997 00 72
29
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
30
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
32
CONNECTION FITTING
35
VALVE (CHECK VALVE)
35
VALVE (CHECK VALVE)
35
VALVE (CHECK VALVE)
36
CONNECTOR AIR RESERVOIR,CONNECTIONS: "11,12"
37
SEAL RINGTO 006 997 00 72
38
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
41
HOLLOW SCREW FUEL LINE TO TANK,659794
41
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
42
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
44
SEAL RINGTO 006 997 00 72
47
T-FITTING FROM CHECK VALVE TO RELAY VALVE
47
T-FITTING FROM CHECK VALVE TO RELAY VALVE
50
NUT CHECK VALVE TO AIR RESERVOIR
50
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
59
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
59
THRUST RING CHECK VALVE TO AIR RESERVOIR
68
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
68
O-RING CHECK VALVE TO AIR RESERVOIR
71
SEAL RING LINE CONNECTION
77
VALVE RELAY KNORR,1D 058160
77
VALVE (RELAY VALVE),REAR AXLE
77
VALVE (RELAY VALVE) KNORR
77
VALVE (RELAY VALVE) WABCO
78
REPAIR KITTO 003 429 30 44,KNORR
78
REPAIR KIT SMALL SCOPE TO 001 429 68 44
78
REPAIR KITWABCO
79
VALVEKNORR,D 058160
80
SOLENOIDTO 693 420 73 71
82
BRACKET REAR AXLE RELAY VALVE
83
SCREW , Replaced By: N304017010040
86
NUT BRACKET TO SIDE MEMBER,XB209706
89
NUT BRACKET TO SIDE MEMBER
90
WASHER TRAILER PLUG SOCKET TO BRACKET
92
BRACKET RELAY VALVE
95
ADAPTER FITTING , Replaced By: A0004296934
98
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
101
TOOTHED WASHER SENDER UNIT TO BRACKET
104
NUT BRACKET TO SIDE MEMBER
107
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
110
SEAL RING LINE CONNECTION
113
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
116
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
119
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
122
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
122
THRUST RING LOCKING VALVE
125
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
128
SEAL RINGTO 006 997 00 72
129
SCREW-IN FITTING OIL LINE CONNECTION
130
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
SWITCH SUPPLY PRESSURE,5 966147
131
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
131
SWITCH FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "23"
131
SWITCH RELAY VALVE,CONNECTION "2"
134
HOLLOW SCREW FUEL LINE TO TANK,659794
134
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
137
SEAL RINGTO 006 997 00 72
140
HOLLOW SCREW FUEL LINE TO TANK,659794
140
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
141
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
143
SEAL RINGTO 006 997 00 72
146
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
149
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
149
THRUST RING LOCKING VALVE
152
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
155
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
155
HOLLOW SCREW FUEL LINE TO TANK,659794
158
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
161
SEAL RINGTO 006 997 00 72
999
ROD , Replaced By: A3842927032, +001A3849967001, +001N000934012009
