Поз.
Артикул
Описание
13
CONNECTOR LEFT FRONT
17
CONNECTOR RIGHT FRONT
21
FLANGE GASKET , Replaced By: A3024900080
21
FLANGE GASKET , Replaced By: A4424920080
21
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
25
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
29
NUT CONNECTOR TO EXHAUST MANIFOLD
38
CONNECTOR INTERMEDIATE PIECE
47
EXHAUST PIPE FRONT LEFT
53
EXHAUST PIPE FRONT RIGHT
61
BRACKET LEFT EXHAUST PIPE
61
BRACKET RIGHT EXHAUST PIPE
65
SCREW , Replaced By: N304017010002
65
SCREW BRACKET TO SIDE MEMBER
65
SCREW REAR EXHAUST PIPE TO MUFFLER
67
NUT , Replaced By: N910113010000
67
NUT STRAP TO BRACKET
69
CLAMP FRONT EXHAUST PIPE TO BRACKET,5 129244
73
SCREW , Replaced By: N304017008027
73
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
76
NUT , Replaced By: N913004008001
76
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
82
EXHAUST MUFFLER ,4 468224
87
CLAMP BRACKET TO FRONT EXHAUST PIPE
93
SCREW , Replaced By: N304017008034
93
SCREW BRACKET TO CROSS CONNECTION STRUT
99
WASHER , Replaced By: N000125008443
99
WASHER EXHAUST MUFFLER TO STRAP
102
NUT , Replaced By: N913004008001
102
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
BRACKET , Replaced By: A3874913041
120
BRACKET
123
SCREW , Replaced By: N308676012026
123
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
126
NUT SUPPORT TO SIDE MEMBER
129
WASHER
132
SCREW , Replaced By: N304017010002
132
SCREW BRACKET TO SIDE MEMBER
135
WASHER , Replaced By: N000125010532
135
WASHER RADIATOR TO RUBBER MOUNTING
138
NUT , Replaced By: N910113010000
138
NUT STRAP TO BRACKET
141
BRACKET EXHAUST MUFFLER TO FRAME,960005
144
BRACKET EXHAUST MUFFLER TO FRAME,960006
147
SCREW CONSOLE TO SIDE MEMBER
150
NUT SUPPORT TO SIDE MEMBER
156
SCREW END PIECE TO EXHAUST PIPE M 10X25
159
NUT , Replaced By: N910113010000
159
NUT STRAP TO BRACKET
163
REAR EXHAUST PIPE ,960005
163
REAR EXHAUST PIPE
169
BRACKET REAR EXHAUST PIPE,4 324718
169
BRACKET REAR EXHAUST PIPE,4 324718
169
BRACKET EXHAUST PIPE SUSPENSION
175
CLAMP REAR EXHAUST PIPE,960005
175
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
175
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
178
SCREW , Replaced By: N304017008027
178
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
181
WASHER , Replaced By: N000125008443
181
WASHER EXHAUST MUFFLER TO STRAP
184
NUT , Replaced By: N913004008001
184
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
217
SCREW , Replaced By: N308676012012
217
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
220
NUT SUPPORT TO SIDE MEMBER
999
EXHAUST MUFFLER
999
BRACKET , Replaced By: A3874914041
999
CLAMP , Replaced By: A3874920240
999
BRACKET , Replaced By: A3874925941
999
BRACKET , Replaced By: A3874926041
999
BRACKET , Replaced By: A3874922841
999
BRACKET , Replaced By: A3874925941
999
BRACKET , Replaced By: A3874926041
999
REAR EXHAUST PIPE , FROM CHASSIS 960006-4 324717, Replaced By: A3874928504, +001A3874926741
999
REAR EXHAUST PIPE , FROM CHASSIS 960006-4 324717, Replaced By: A3874928604, +001A3874926641
999
BRACKET REAR EXHAUST PIPE,4 324717
