Поз.
Артикул
Описание
6
HEAT EXCHANGER , Replaced By: A0008350101
6
HEAT EXCHANGER LEFT
8
CONTROL VALVE LEFT
10
SEAL , Replaced By: A0008355898
10
SEAL OUTSIDE
12
WEATHERSTRIP HEAT EXCHANGER
14
WEATHERSTRIP HEAT EXCHANGER
16
PIPE LINE
20
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
20
HOSE , Replaced By: N900271015037
22
HOSE , Replaced By: N900271015037
22
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
24
MOTOR , FROM CHASSIS:110.010 128152 110.110 218650 111.010 039988 111.012 086050 111.014 085830 112.014,015 002661
26
FAN PLASTIC, 000,001,002,003,004,005,010,011 FROM CHASSIS 128152,100,101,104,110 FROM CHASSIS 218650
28
GROMMET
30
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
32
WEATHERSTRIP
34
SPRING
36
GROMMET
40
NUT RETAINER DRIVE TO REAR PILLAR
44
DEFROSTER NOZZLE LEFT
56
MOUNTING MOSS TYPE RUBBER
58
RUBBER SEAL DEFROSTER NOZZLE,115 MM, ORDER BY THE METER
60
SCREEN
62
AIR DISTRIBUTOR
64
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
66
SEAL
68
OPERATING LEVER WITH ROLLERS
70
SPRING
72
ESCUTCHEON , FROM DATE OF INSTALLATION OF SAFETY STEERING (COLLAPSIBLE COLLAR)
74
WASHER
76
OPERATING HANDLE , 000,001,004,010 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTNOTE 43,002,003,005,011 UP TO CHASSIS 034216 EXCEPT FOR,SEE FOOTNOTE 4 4,AND FOOTNOTE 013
78
WIRE CABLE
80
SPIRAL , ORDER BY THE METER
82
SCREW WIRE CABLE
84
BUSHING
88
CLIP , ALSO APPLICABLE TO VERSION 55705/11-/62
90
CLAMP WIRE CABLE TO DEFROSTER NOZZLE BEARING BRACKET,RIGHT, 000,001,004,010 FROM CHASSIS 114258,100,101,104,110 FROM CHASSIS 191759
98
WIRE CABLE FRESH AIR FLAP
100
SPIRAL , ORDER BY THE METER
114
WIRE CABLE
118
PROTECTIVE CAP WIRE CABLE TO AIR FLAP
118
GROMMET , Replaced By: A1093270059
120
GROMMET
120
GROMMET
134
INTERMEDIATE PIECE HEATING IN THE REAR
144
AIR DUCT
148
DUCT LEFT, 000,001,004,010 FROM CHASSIS 000066,100,101,104,110 FROM CHASSIS 000006
152
RUBBER RING BETWEEN DUCT AND CROSS MEMBER, 000,001,004,010 FROM CHASSIS 000066,100,101,104,110 FROM CHASSIS 000006
164
NOZZLE LEFT
166
VALVE
168
SPRING
170
HOSE 168 MM
172
VALVE , 000,001,004,010 UP TO CHASSIS 152805,002,003,005,011 UP TO CHASSIS 012119,100,101,104,110 UP TO CHASSIS 267732
174
GROMMET 34 MM
176
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
188
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
198
GROMMET 34 MM
200
CAP
202
GRILLE
206
LOCK , Replaced By: A1409941045
206
LOCK FUEL LINE
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: A0059970190
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
SPRING WASHER
999
WASHER
999
SCREW LINE TO CROSS MEMBER
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW REFLECTOR TO BUMPER
999
SHEET METAL SCREW INTERIOR LAMP B 3.5X13
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
LOCK PLATE
999
TOOTHED WASHER
999
NUT BALL PIVOT TO LEVER
999
NUT TACHOGRAPH TO BRACKET
999
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
SCREW COVER PLATE TO BRACKET
999
SCREW OIL LINE TO CRANKCASE
999
SCREW
999
SCREW WIRE CABLE TO DEFROSTER NOZZLE BEARING BRACKET,RIGHT
999
SCREW WIRE CABLE TO BRACKET OF BEARING BRACKET
999
WASHER
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SHEET METAL SCREW MODULE TO HOUSING
999
WIRE CABLE , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A1218330431
999
BUSHING AT LEFT DEFROSTER NOZZLE,FOR WIRE CABLE
999
SCREW , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A1368310089
999
SPRING , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A1868880034
999
HOSE , Replaced By: A1108310188
999
WIRE CLAMP , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A1208310032
999
RUBBER BUFFER
999
OPERATING HANDLE , Replaced By: A3418337040
999
DEFROSTER NOZZLE RIGHT
999
HEATER CASE , Replaced By: A1118305962
999
OPERATING LEVER , Replaced By: A1118305633
999
DEFROSTER NOZZLE , Replaced By: A1118305619
999
ESCUTCHEON , Replaced By: A1118305089
999
DEFROSTER NOZZLE , UP TO CHASSIS 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002 797,002862, Replaced By: A1118305519, +001G401218330431
999
PIPE LINE RETURN TO HEAT EXCHANGER
999
NOZZLE RIGHT
999
GROMMET FEED LINE THRU FIRE WALL,BOTTOM LEFT
999
SPIRAL , Replaced By: A1118336130
999
LEVER LEFT
999
DUCT RIGHT, 000,001,004,010 FROM CHASSIS 000066,100,101,104,110 FROM CHASSIS 000006
999
LEVER RIGHT
999
HOSE CLAMP LINE MOUNTING
999
GROMMET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009974981
999
WIRE SPIRAL , ORDER BY THE METER
999
WASHER CLEARANCE LAMP ON BRACKET
999
FOAM PLASTICS FRONT ROOF RAIL
999
FOAM PLASTICS , Replaced By: A0009833598
999
SEAL
999
CARBON BRUSH SET , 000,001,002,003,004,005,010,011 FROM CHASSIS 128152,100,101,104,110 FROM CHASSIS 218650
999
CONTROL VALVE RIGHT
999
HEAT EXCHANGER , Replaced By: A0008350201
999
HEAT EXCHANGER ON SPECIAL REQUEST,WITH A HIGHER HEATING POWER
999
SEAL , Replaced By: A0008351298
