Поз.
Артикул
Описание
10
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
14
SPRING
17
RELEASE LEVER , ON SPECIAL REQUEST, H.D. CLUTCH
22
PIN
26
CLAMPING SLEEVE
30
SPACER RING
34
NUTTO 001 250 03 04
34
NUT , Replaced By: A0002522772
37
PRESSURE SPRING CLUTCH PRESSURE PLATE
41
SLEEVE
45
THRUST WASHER
49
CLUTCH DISC SPLINE-SHAFT SECTION, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
54
SCREW , Replaced By: N304017008034
58
LOCK WASHER TAIL LAMP TO BRACKET
66
HYDRAULIC CLUTCH , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
72
SCREW PLUG
75
SEAL RING
107
HOUSING
113
STUD TAIL-, BRAKE-, AND TURN SIGNAL LIGHTS
122
HOUSING HYDRAULIC CLUTCH
125
COVER PLATE
147
BOOT
152
SEAL HOLDER
156
SCREW COVER PLATE TO COVER PLATE M 6 X 12
156
SCREW , Replaced By: N304017006018
161
SCREW , Replaced By: A0089907401
161
SCREW BRACKET TO SIDE MEMBER,K 168169
165
SPRING WASHER GROUND CABLE TO TRANSMISSION
204
RELEASE BEARING
209
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
216
RELEASE YOKE
224
SPRING
227
SNAP RING
230
SLAVE CYLINDER , 010 FROM CHASSIS 048977,012 FROM CHASSIS 108750 NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
234
PIN
236
BOOT ,027649
241
VALVE
245
PROTECTIVE CAP , Replaced By: A0004217187
245
PROTECTIVE CAP ,5 962906
249
REPAIR KIT ,027649
260
ROD
263
NUT
263
NUT , Replaced By: N304035008001
266
SPRING
999
RIVET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
CLUTCH LINING , Replaced By: A1085860025
999
CLUTCH LINING ON FLYWHEEL END, NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
REPAIR KIT , 014 FROM CHASSIS 049462,021 FROM CHASSIS 049449,023 FROM CHASSIS 049723
999
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
999
REPAIR KIT ON CLUTCH END, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
RELEASE BEARING , ON SPECIAL REQUEST, H.D. CLUTCH
999
HYDRAULIC CLUTCH , 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
999
WASHER BRACKET TO REAR CROSS MEMBER
999
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER CAB FLOOR
999
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
999
SCREW HYDRAULIC CLUTCH TO ENGINE, 021,023 UP TO CHASSIS 086009
999
SCREW CONNECTOR TO EXHAUST MANIFOLD
999
SCREW COVER PLATE TO BRACKET
999
SCREW PRESSURE REGULATOR WITH TIRE INFLATOR CONNECTION TO SUBSTRUCTURE
999
SCREW , Replaced By: N304017012002
999
NUT
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW PUMP TO BRACKET
999
SCREW PIPE CLAMP
