Поз.
Артикул
Описание
110
COMBINATION BOLT
218
PIPE LINE FROM ENGINE TO HEAT EXCHANGER
242
PIPE LINE FROM WATER VALVE TO RECIRCULATING PUMP
248
SHEET METAL SCREW BRACKET TO CAB FLOOR
257
HOSE BETWEEN ENGINE AND FEED LINE
260
RUBBER RING
263
HOSE FROM FEED LINE TO LEFT HEAT EXCHANGER
266
HOSE FROM FEED LINE TO RIGHT HEAT EXCHANGER
290
HOSE RETURN FROM WATER VALVE TO ENGINE
293
HOSE FROM WATER VALVE TO WATER PUMP RETURN LINE
296
HOSE FROM RECIRCULATING PUMP TO RETURN LINE
323
HOSE CLAMP LINE MOUNTING
323
CLAMP , Replaced By: A0059970190
326
CLAMP , Replaced By: N000000000667
326
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
329
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
329
CLAMP PRESSURE REGULATOR
335
EXPANSION PLUG IN FLOOR,FRONT
