Поз.
Артикул
Описание
5
BATTERY PARTS KIT
5
BATTERY FILLED 12V/100 AH, Replaced By: A0055412501
11
BOOT POS. POLE
38
POSITIVE CABLE FROM BATTERY TO STARTING MOTOR
49
BRACKET
53
PLUG HOUSING INBOARD CABLE HARNESS PLUG-CONNECTION
54
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
57
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
60
PLUG. PIN BUSHING HOUSING NTC FEELER
61
GROMMETTO 014 545 07 28
62
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
65
GROMMET CABLE TO STARTING MOTOR
82
SHEET METAL SCREW ELECTRIC CABLE THRU CAB FLOOR
82
TAPPING SCREW BRACKET TO CAB FLOOR
89
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
92
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
95
SCREW PUMP TO BRACKET
95
SCREW , Replaced By: N304017006016
104
NUT BALL PIVOT TO LEVER
107
SPRING WASHER LICENSE PLATE TO BRACKET
108
COVERING CABLE TO STARTING MOTOR,TERMINAL 50
116
SOCKET-TERMINAL STRIP SPRING DOME
131
LOCK FRONT PANEL,LATERAL RIGHT,9/87
146
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
146
SCREW COVER PLATE TO COVER PLATE M 6 X 10
146
SCREW , Replaced By: N007985004107
149
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
152
LOCK WASHER T-FITTING TO BRACKET
155
NUT BALL PIVOT TO LEVER
158
NEG. CABLE FROM BATTERY NEG. POLE TO GROUND 220 MM
164
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
167
SPRING WASHER , Replaced By: N000137008212
170
NEG. CABLE , Replaced By: A9015400741
176
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
179
SPRING WASHER , Replaced By: N000137008212
182
CABLE HARNESS FROM ALTERNATOR TO CABLE CONNECTOR 120 A
182
CABLE HARNESS FROM ALTERNATOR TO CABLE CONNECTOR
193
BRACKET ALTERNATOR CABLE HARNESS
199
SHEET METAL SCREW BRACKET TO CAB FLOOR
202
NUT , Replaced By: N304032008006
202
NUT TACHOGRAPH TO BRACKET
202
NUT
205
LOCK WASHER T-FITTING TO BRACKET
205
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
214
CAP SCREW HEAD COVERING
214
PROTECTION CAP , Replaced By: A0008310929
