Поз.
Артикул
Описание
130
RECIRCULATING PUMP ,F 185093 NOT FOR AUSTRALIA
130
RECIRCULATING PUMP ,5/91
130
RECIRCULATING PUMP"SWF",5/91
130
RECIRCULATING PUMP. PUMP , NOT FOR AUSTRALIA
135
BRACKET
140
CLIP PLUG TO REAR PILLAR
145
SCREW BRACKET TO FIRE WALL
145
SHEET METAL SCREW , Replaced By: N000000000542
150
PIPE LINE FROM ENGINE TO HEAT EXCHANGER, B 26179202/93
150
PIPE LINE FROM ENGINE TO HEAT EXCHANGER
155
HOSE
160
HOSE CLAMP LINE MOUNTING
165
PIPE LINE
170
RUBBER RING
175
HOSE
180
HOSE CLAMP LINE MOUNTING
185
PIPE LINE
190
PIPE LINE
195
PIPE LINE
200
PIPE LINE
205
FITTING (PARTS KIT),LINE RUPTURE
210
CLAMP
215
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
220
CLAMP
225
CLAMP
230
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
235
CLAMP
240
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
245
BRACKET
250
CLAMP
255
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
260
HOSE
265
HOSE CLAMP LINE MOUNTING
270
HOSE
275
HOSE CLAMP LINE MOUNTING
275
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
275
CLAMP , Replaced By: N000000000667
285
HOSE
290
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
290
HOSE CLAMP LINE MOUNTING
290
CLAMP , Replaced By: N000000000667
300
CLAMP , 107.022 005200 EXCEPT FOR 005190-005192,005194-005199. 107.023 012496 107.024 021803 EXCEPT FOR 021794,021804
305
GROMMET
310
BRACKET
315
SHEET METAL SCREW ALARM UNIT TO STRUT
320
HOSE CLAMP LINE MOUNTING
325
HOSE FROM RETURN LINE TO RECIRCULATING PUMP,9/88 ONLY USED WITH AUXILIARY HEATER
325
HOSE FROM RETURN LINE TO RECIRCULATING PUMP,9/88 USED WITHOUT AUXILIARY HEATER
325
HOSE FROM RETURN LINE TO RECIRCULATING PUMP,9/88 USED WITHOUT AUXILIARY HEATER
325
HOSE FROM RETURN LINE TO RECIRCULATING PUMP,9/88 ONLY USED WITH AUXILIARY HEATER
327
HOSE HAND BRAKE VALVE BLEEDING, ORDER BY THE METER
328
HOSE CLAMP LINE MOUNTING
330
HOSE FROM DOUBLE WATER VALVE TO RETURN LINE
340
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
345
HOSE FROM RECIRCULATING PUMP TO ENGINE
350
CLAMP , Replaced By: N000000000667
350
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
