Главная
›
Mercedes
›
CAR
›
250 D TURBODIESEL
›
124.128 200-300 9/89-10/92, 200D-300D 9/89-7/93
›
61 SUBSTRUCTURE
›
015 FRONT FLOOR
Mercedes A1166160020 - ОПОРА МЕТАЛЛОРЕЗИНОВАЯ
250 D TURBODIESEL 124.128 200-300 9/89-10/92, 200D-300D 9/89-7/93
61 SUBSTRUCTURE - 015 FRONT FLOOR
Поз.
Артикул
Описание
5
A1246101360
MAIN FLOOR LEFT
8
A1246101460
MAIN FLOOR RIGHT, TO BE ADAPTED DURING ASSEMBLY
11
A1269840025
THREADED CHUCK SAFETY BELT MOUNTING
20
A1246100671
TUNNEL
23
A1246102836
BRACKET (SENSOR)
32
A1246110122
SIDE MEMBER FRONT LEFT
32
A1246110222
SIDE MEMBER FRONT RIGHT
35
A1246100120
CROSS MEMBER BELOW FRONT SEAT,FRONT LEFT
35
A1246100220
CROSS MEMBER BELOW FRONT SEAT,FRONT RIGHT
38
A1246100620
CROSS MEMBER BELOW FRONT SEAT,REAR RIGHT
38
A1246100520
CROSS MEMBER BELOW FRONT SEAT,REAR LEFT
41
A1246160231
CONSOLE FRONT SEAT BRACING
44
A1246160031
CONSOLE CABLE PASSAGE
47
A1246102325
REINFORCEMENT CROSSMEMBER DRIVER'S SEAT WITH CAT BRACKET
50
A1246101131
CONSOLE LEFT, A 061921
50
A1246101231
CONSOLE RIGHT, A 061921
53
N900161008109
SCREW BRACING TO TUNNEL
56
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
59
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
65
A1246100052
TAKE-UP DEVICE PROPELLER SHAFT BEARING IN TUNNEL CENTER
92
A1166160020
MOUNTING ACCELERATOR PEDAL, AT FRONT FLOOR
