Поз.
Артикул
Описание
5
FUEL HOSE FROM TANK FILTER TO FUEL PUMP
5
FUEL HOSE FROM TANK FILTER TO FUEL PUMP
8
GROMMET BATTERY CASE
14
FUEL HOSE FROM FUEL PUMP TO ACCUMULATOR
17
CLAMP FROM VENT PIPE TO FILLER NECK
20
CLAMP LINE CONNECTION
23
FUEL HOSE , Replaced By: A1244708075
23
FUEL HOSE FROM FUEL FILTER TO FEED LINE,C 226335
24
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
24
HOSE FROM FUEL FILTER TO FEED LINE, Replaced By: A1149971882
24
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
24
HOSE FROM FEED LINE TO FILTER 240 MM
25
HOSE CLAMP HOSE ATTACHMENT
62
LINE RETURN
65
HOSE FROM RETURN LINE TO FUEL TANK
68
LOOM TIE
71
DAMPING STRIP FUEL LINES TO VEHICLE FLOOR
74
CLAMP BRAKE LINE TO FIRE WALL, 000 130186 003 066451 007 053318 083 002304 086 001762 093 001874 102,103 113215 105 135079 183 004049 190 005029
77
NUT COVERING TO CAB FIRE WALL
83
DAMPING STRIP BRAKE LINE TO SIDE MEMBER
86
CLAMP
92
DAMPING STRIP FUEL AND BRAKE LINES TO ENGINE CROSS MEMBER,F 106839
95
CLAMP FUEL & BRAKE LINES TO LEFT SIDE MEMBER, NOT FOR R.S.A.
98
DAMPING STRIP
101
CLAMP FORKED SUPPORT,TOP
104
DAMPING STRIP FUEL & BRAKE LINES TO LEFT SIDE MEMBER
107
CLAMP FUEL & BRAKE LINES TO LEFT SIDE MEMBER
110
SHEET METAL SCREW VALVE TO WINDOW SILL
113
DAMPING STRIP
116
CLAMP
119
CLAMPING ELEMENT FLOOR BELOW REAR SEAT
