Поз.
Артикул
Описание
221
BEARING BRACKET , BIS MOTOR 130.983 011336
224
LEVER , BIS MOTOR 130.983 011336
225
LOCK PLATE RELEASE LEVER TO SHAFT
226
BUSHING
226
BUSHING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 015 203557 017 002324 110 404833 105,107,108,117,119,001920 115 204352, Replaced By: A1150720450
230
THROTTLE HOUSING
231
SWITCH
233
SCREW
234
VACUUM BOX , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
235
BRACKET , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
236
SCREW , UP TO ENGINE 920 001710 923 000785 924 000001 926 000011
236
SCREW , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
237
NUT CLAMP TO BRACKET
238
SPRING , Replaced By: A0000717416
238
SPRING
239
NUT , Replaced By: N308675012000
239
NUT CAB FLOOR
240
WASHER , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
241
WASHER , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
243
BUSHING , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
244
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
244
WASHER , Replaced By: N009021005205
251
NUT , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
267
INJECTION PUMP
267
INJECTION PUMP , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 130.980 10/50,20/60 022057 130.980 12/52,22/62 049814 130.983 10/50,20/60 007194 130.983 12/52,22/62 013291, Replaced By: A1300701701
268
BRACKET
269
GASKET
271
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
271
LOCK WASHER
272
SCREW
273
VALVE
275
BRACKET
276
SCREW PUMP TO BRACKET
276
SCREW COVER PLATE TO BRACKET
277
SCREW ELECTRIC CABLE TO HORN
278
LOCK WASHER T-FITTING TO BRACKET
283
ROD , UP TO ENGINE: 130.980 12/52 049814 130.983 12/52 013291
285
ROD , Replaced By: A0000700675
285
ROD , FROM ENGINE: 130.980 12/52 049815 130.983 12/52 013292
286
CONICAL CUPTO 102 070 09 75
286
BALL SOCKET , Replaced By: A0009918922
286
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
288
NUT TACHOGRAPH TO BRACKET
999
PISTON RING PISTON RINGS, NO LONGER AVAILABLE
999
PISTON RING PISTON RINGS, NO LONGER AVAILABLE
999
SETSCREW. STUD
999
MAGNET
999
CARBURETOR
999
IGNITION DISTRIBUTOR
999
CARBURETOR REAR
999
REPAIR KIT , Replaced By: A0000307524
999
REPAIR KIT , Replaced By: A0000307624
999
REPAIR KIT , Replaced By: A0035866303
999
REPAIR KIT PISTON RINGS, NO LONGER AVAILABLE
999
REPAIR KIT PISTON RINGS, NO LONGER AVAILABLE
999
SPARK PLUG
999
ENGINE , Replaced By: A1140109100
999
ENGINE , Replaced By: A1140109200
999
ENGINE , MECHANICAL TRANSMISSION
999
ENGINE , AUTOMATIC TRANSMISSION
999
PISTON INTERMEDIATE SIZE, NO LONGER AVAILABLE
999
PISTON REPAIR SIZE I, NO LONGER AVAILABLE
999
PISTON REPAIR SIZE III, NO LONGER AVAILABLE
999
NUT
999
BRACKET
999
ENGINE , MECHANICAL TRANSMISSION ONLY APPLICABLE TO MODEL 130.920
999
ENGINE , AUTOMATIC TRANSMISSION ONLY APPLICABLE TO MODEL 130.920
999
ENGINE , MECHANICAL TRANSMISSION ONLY APPLICABLE TO MODEL 130.923
999
ENGINE , AUTOMATIC TRANSMISSION ONLY APPLICABLE TO MODEL 130.923
999
ENGINE
999
ENGINE
999
ENGINE
999
ENGINE
999
ENGINE
999
PISTON , Replaced By: A1300308017
999
PISTON , Replaced By: A1300308317
999
PISTON , Replaced By: A1300308017
999
PISTON , Replaced By: A1300308317
999
PISTON INTERMEDIATE SIZE, NO LONGER AVAILABLE
999
PISTON REPAIR SIZE III, NO LONGER AVAILABLE
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
SCREW PLUG TRANSMISSION CASE,BOTTOM
999
NUT CABLE TO ALTERNATOR,4 477130
999
SCREW PLUG OIL FILLING
