Поз.
Артикул
Описание
10
REFRIGERANT LINE FROM COMPRESSOR TO CONDENSER
20
SEAL RING FROM LIQUID TANK TO T-FITTING
20
SEALING RING PIPE LINE TO REFRIGERANT COMPRESSOR 10.6X2 MM
30
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
50
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
80
CAPACITOR
80
CONDENSER , Replaced By: A2045000654
90
PRESSURE SENSORM 10, Replaced By: A2110000283
90
PRESSURE SENSOR
120
REFRIGERANT LINE CONDENSER TO EXPANSION VALVE
120
REFRIGERANT LINE CONDENSER TO EXPANSION VALVE
120
REFRIGERANT LINE CONDENSER TO EXPANSION VALVE
120
REFRIGERANT LINE CONDENSER TO EXPANSION VALVE
120
REFRIGERANT LINE CONDENSER TO EXPANSION VALVE
130
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
140
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
140
O-RING PRESSURE LINE TO EXPANSION VALVE 7.5X2.1, J 48712220070601
145
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
150
VALVE INSERT TO REFRIGERANT LINE OF COMPRESSOR TO CONDENSER
155
GUIDE PRESSURE LINE TO CONDENSER
160
CAP
180
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
200
NUT , Replaced By: N913023006001
250
REFRIGERANT LINE FROM EXPANSION VALVE TO SEPARATION POINT
250
REFRIGERANT LINE FROM EXPANSION VALVE TO SEPARATION POINT
250
REFRIGERANT LINE FROM EXPANSION VALVE TO SEPARATION POINT
260
SEALING RING REFRIGERANT LINE 14.0X2.0
260
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
260
SEAL RING HOSE TO CONDENSER 14 MM
270
VALVE INSERT TO REFRIGERANT LINE OF COMPRESSOR TO CONDENSER
280
CAP , NOT USED
310
GROMMET MOUNTING, REFRIGERANT LINE
320
FASTENER BUTTON AT SOLENOID VALVE,A 258245
350
REFRIGERANT LINE FROM SEPARATION POINT TO COMPRESSOR
360
SEAL RING
365
SEALING RING SUCTION LINE 13.7X2.5 MM
370
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
380
NUT , Replaced By: N913023006001
400
GROMMET PIPE THROUGH PARTITION WALL, UPPER SECTION
400
FEED-THROUGH GROMMET PIPE THROUGH PARTITION WALL, UPPER SECTION
410
GROMMET PIPE THROUGH PARTITION WALL, LOWER SECTION
410
FEED-THROUGH GROMMET PIPE THROUGH PARTITION WALL, LOWER SECTION
430
LINE HOLDER FUEL LINE MOUNTING
450
CLAMP6/14-15 MM
460
CLAMP HOSE TO HOSE 20 MM
470
NUT , Replaced By: N913023006001
480
NUT , Replaced By: N913023006001
500
CLAMP MOUNTING PIPE LINE
510
NUT COVERING TO CAB FIRE WALL
900
CLUTCH. PIN BUSHING HOUSING SIREN
