Поз.
Артикул
Описание
5
ALTERNATOR12V/120A, VALEO, F 183861 (COUPE) T 069001 (COUPE), T 077901 (CABRIO) PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR12V/115A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR12V/120A, BOSCH, F 183861 (COUPE) T 069001 (COUPE), T 077901 (CABRIO) PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
PULLEY
8
PULLEY BOSCH ALTERNATOR
11
NUT PULLEY TO ALTERNATOR
14
SCREW COVER PLATE TO DRIVE BEARING M4X20
14
SCREW. BOLT FRONT BALL BEARING FASTENING M4X22.6 MM,BOSCH
20
BALL BEARING DRIVE END BEARING TO A 011 154 94 02, 9202
20
BALL BEARING DRIVE END BEARING BOSCH
20
BALL BEARING , Replaced By: A0079818925
23
BALL BEARING SLIP RING SIDE TO A 011 154 94 02, 92 02, Replaced By: A0089818625
23
BALL BEARING , Replaced By: A0079817325
23
BALL BEARING REAR
23
BALL BEARING SLIP RING SIDE BOSCH
26
RINGBOSCH
26
RING SLIP RING SIDE
29
BOLT. SCREW
29
SCREW HOUSING M5X47, BOSCH
32
SCREW
35
SCREW RECTIFIER TO A 011 154 94 02, 92 02
38
REGULATOR AND CUT-OUTBOSCH
41
REGULATOR AND CUT-OUTVALEO, TO A 011 154 66 02
41
REGULATOR AND CUT-OUTTO A 012 154 09 12, A 012 154 03 02
44
SCREW T-FITTING TO BRACKET M4X25
47
SCREW REGULATOR AND CUT-OUT
50
COVERBOSCH
53
COVERTO A 013 154 13 02,15 02,17 02, 203 A 237173 203 F 177684 203 R 028781 210 B 438526 210 X 065664 901-904 R337626 638 246705 SEE CHASSIS PARTS KIT FOR "FROM VIN" NO.
53
COVERVALEO
56
SCREW COVER BOSCH
59
NUT COVER TO A 011 154 94 02, 92 02
62
NUT BOOT M8,BOSCH
65
SCREW ALTENATOR ON TIMING CASE AND WATER PUMP M10X95
65
SCREW ALTENATOR ON TIMING CASE AND WATER PUMPM10X105
65
SCREW , Replaced By: N000000001143
71
BRACKET , Replaced By: A1122030140
71
BRACKET AT ALTERNATOR
74
BRACKET AT BRACKET
