Поз.
Артикул
Описание
10
DOOR SHELL LEFT
10
DOOR SHELL LEFT
10
DOOR SHELL RIGHT
10
DOOR SHELL LEFT
10
DOOR SHELL RIGHT
10
DOOR SHELL LEFT
10
DOOR SHELL RIGHT
10
DOOR SHELL RIGHT
10
DOOR SHELL LEFT
10
DOOR SHELL RIGHT
20
PANELLING LEFT
20
PANELLING RIGHT
30
HINGE LEFT AND RIGHT
30
HINGE LEFT AND RIGHT
40
SCREW DRIVER'S DOOR ON A-PILLAR
45
CAP TO RIGHT DOOR HINGE SCREW
50
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
50
SCREW FRONT DOOR TO FRONT PANEL PILLAR
50
SCREW HINGE TO FRONT DOOR
60
DOOR CHECK FRONT DOORS
60
DOOR CHECK LEFT AND RIGHT, Replaced By: A2107200116
60
DOOR CHECK LEFT AND RIGHT, RECOMMENDED FOR TAKING ON STOCK
65
PIN DOOR CHECK TO CENTRAL PILLAR
70
LOCK
80
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
80
SCREW
80
SCREW DOOR CHECK TO DOOR M6X18
90
SCREW DOOR BRAKE ON A-PILLAR
90
SCREW DOOR BRAKE ON A-PILLAR
95
SPRING DOOR OPENING ASSIST
97
PAD BELOW DOOR HINGE 2MM
97
PAD BELOW DOOR HINGE 2,5MM
97
PAD BELOW DOOR HINGE 3MM
110
WEATHERSTRIP RIGHT FRONT DOOR
110
WEATHERSTRIP LEFT FRONT DOOR
115
CLIP SEAL TO REAR DOOR
120
SEAL DOOR CHECK
130
BRACKET , Replaced By: A1707230014
130
BRACKET DOOR CHECK
150
GARNISH MOULDING LEFT DOOR EDGE, RECOMMENDED FOR TAKING ON STOCK
150
GARNISH MOULDING RIGHT DOOR EDGE
160
CLIP TRIM STRIP IN AREA OF TRIM PANEL
170
RIVET REFLECTOR TO BRACKET
180
FILLER BOTTOM REAR LEFT
180
FILLER BOTTOM REAR RIGHT, RECOMMENDED FOR TAKING ON STOCK
190
LEDGE RIGHT DOORS, BOTTOM
190
LEDGE LEFT DOORS, BOTTOM
200
FASTENER BUTTON
210
ORNAMENTAL COVER WINDOW FRAME,LEFT ELEGANCE
210
ORNAMENTAL COVER WINDOW FRAME,RIGHT CLASSIC, RECOMMENDED FOR TAKING ON STOCK
210
ORNAMENTAL COVER WINDOW FRAME,LEFT AVANTGARDE
210
ORNAMENTAL COVER WINDOW FRAME,RIGHT AVANTGARDE
220
PAD RIGHT
220
PAD LEFT, RECOMMENDED FOR TAKING ON STOCK
230
LOCK AT BRACKET,F 029921
240
TAPPING SCREW DECORATIVE MOULDING ON REAR DOOR
240
TAPPING SCREW ROOF MOUNTED OPERATING UNIT
250
INTERMEDIATE LAYER BETWEEN WINDOW FRAME AND MOULDING, RECOMMENDED FOR TAKING ON STOCK
260
INSULATION
260
INSULATION
300
SIDEBAG RIGHT FRONT DOOR, A 177064 J 024802 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 177063, J 024801 WITH CODE 807
300
SIDEBAG , A 177064 J 024802 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 177063, J 024801 WITH CODE 807, Replaced By: A2108601105
300
SIDEBAG RIGHT FRONT DOOR, A 177064 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 177063 WITH CODE 807, Replaced By: A2108601205
300
SIDEBAG LEFT FRONT DOOR, A 177063 J 024801 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 177064, J 024802 WITH CODE 806
310
BLIND RIVET GRAB HANDLE BRACKET TO INTERIOR PLATE, A 328811 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 328810 WITH CODE 807
