Поз.
Артикул
Описание
20
PILLAR A-PILLAR,INSIDE LEFT
20
PILLAR A-PILLAR,INSIDE RIGHT
30
STIFFENING SIDE MEMBER,INSIDE LEFT
30
STIFFENING SIDE MEMBER,INSIDE RIGHT
40
PILLAR A-PILLAR OUTSIDE RIGHT,WITH SIDE MEMBER
40
PILLAR A-PILLAR OUTSIDE LEFT,WITH SIDE MEMBER
40
PILLAR A-PILLAR OUTSIDE LEFT,WITH SIDE MEMBER, Replaced By: A2306300910, +003A0019902659
50
RIVET GAP SEAL B PILLAR RIGHT
55
PAD TO BUFFER
60
SIDE PANEL WITH SIDE MEMBER,REAR RIGTH
60
SIDE PANEL WITH SIDE MEMBER,REAR LEFT
60
SIDE PANEL WITH SIDE MEMBER,REAR LEFT, Replaced By: A2306300701, +003A0019902659
60
SIDE PANEL WITH FENDER,RIGHT REAR
60
SIDE PANEL WITH FENDER,LEFT REAR
70
END PIECE B-PILLAR ON THE LEFT
70
END PIECE B-PILLAR ON THE RIGHT
80
WHEELHOUSE REAR INSIDE, LEFT
80
WHEELHOUSE FRONT OUTSIDE LEFT
80
WHEELHOUSE REAR INSIDE RIGHT
80
WHEELHOUSE FRONT OUTSIDE RIGHT
90
BOTTOM LATERAL LEFT, OBSERVE WIS
90
BOTTOM LATERAL RIGHT
100
PILLAR REAR OUTSIDE LEFT
100
PILLAR REAR OUTSIDE RIGHT
110
WELDING PIECE LEFT
110
WELDING PIECE RIGHT
115
CONSOLE RIGHT LOCK
115
CONSOLE LEFT LOCK
120
CONSOLE REAR RIGHT
120
CONSOLE REAR LEFT
125
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
128
RIVETED NUT NET RETAINER M6
130
SUPPORT B-PILLAR, LEFT REAR
130
SUPPORT B-PILLAR, RIGHT REAR
140
SUPPORT B-PILLAR, LEFT FRONT
140
SUPPORT B-PILLAR, RIGHT FRONT
160
COVER LEFT FRONT SIDE MEMBER
160
COVER RIGHT FRONT SIDE MEMBER
160
COVER RIGHT FRONT SIDE MEMBER
160
COVER LEFT FRONT SIDE MEMBER
170
REINFORCEMENT LEFT SIDE MEMBER
170
REINFORCEMENT RIGHT SIDE MEMBER
400
ROOF RAIL FRONT INSIDE
410
ROOF RAIL FRONT OUTSIDE
420
NUT AT ROOF REAR RAIL
430
PROTECTIVE FOIL LEFT
430
PROTECTIVE FOIL RIGHT
600
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
610
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
999
BRACKET
