Поз.
Артикул
Описание
777
PARKING BRAKE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
778
RATCHET ROD
779
SPACER RING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
780
GROOVED PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
781
PROTECTIVE CAP , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
782
BEARING BRACKET , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
783
GROOVED PIN
784
DRUCKFEDER. SPRING , Replaced By: A3145860142
784
PAWL , Replaced By: A3145860142
784
PLATE , Replaced By: A3145860142
784
REPAIR KIT , Replaced By: A3144200092
784
REPAIR KIT
785
LOCK RING
786
DAMPING RING
787
HANDLE
789
HANDLETO 341 420 00 88
790
SCREW
791
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
792
PART NAME MISSING
793
SCREW
798
SCREW , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
798
SCREW RUBBER BUFFER TO PLATE
799
SHIM SHIM, 674067
800
LOCK WASHER RAIL TO BATTERY SUPPORT
801
NUT LEVER TO SHIFTING SHAFT
802
PIN ROD TO INTERMEDIATE LEVER
803
WASHER PULL ROD TO SHIFT LEVER
804
COTTER PIN PULL ROD TO SHIFTING SHAFT
807
BRAKE LEVER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
807
BRAKE LEVER , Replaced By: A3444200112
808
BUSHING , Replaced By: A3449920301
808
BUSHING
809
GREASE NIPPLE PROTECTIVE TUBE
810
BEARING BRACKET BRAKE CABLE, 674067
811
WASHER BRAKE LEVER TO BEARING BRACKET, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
812
LOCK RING22X1.2,TO 001 431 71 14
813
SCREW CROSS MEMBER TO SIDE MEMBERS
813
SCREW , Replaced By: N304017010002
814
LOCK WASHER , Replaced By: N912004010102
815
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
848
END PIECE
849
ROD , Replaced By: A3444200274
849
ROD , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
849
PULL ROD
850
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
851
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
852
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
853
COTTER PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
858
BEARING BRACKET , Replaced By: A3444200478
858
BEARING BRACKET , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
859
LEVER , Replaced By: A3444200081
859
LEVER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
860
LEVER
861
BUSHING
861
BUSHING , Replaced By: A3449920301
862
GREASE NIPPLE
863
PIN
864
WASHER BRAKE LEVER TO BEARING BRACKET, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
865
LOCK RING22X1.2,TO 001 431 71 14
866
GREASE NIPPLE PROTECTIVE TUBE
870
SCREW , Replaced By: N304017010040
870
SCREW , Replaced By: N304017010002
871
LOCK WASHER , Replaced By: N912004010102
872
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
SPRING
999
PISTON
999
THRUST PIN
999
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
999
HOLLOW SCREW
999
CONNECTOR
999
PROTECTIVE CAP BRAKE BOOSTER
999
WHEEL BRAKE CYLINDER
999
CABLE PULLEYTO 044 420 01 18
999
PROTECTIVE CAP
999
DISTRIBUTOR , Replaced By: A3454287024
999
CONNECTOR BRAKE LINE TO BRAKE MASTER CYLINDER, ONLY ON INSTALLATION OF DIAPHRAGM CYLINDER OF MAKE "WESTINGHOUSE"
999
HOLLOW SCREW AT BRAKE MASTER CYLINDER
999
VALVE , Replaced By: A3454307081
999
FILLER CAP
999
STRAINER , Replaced By: A3084317034
999
WASHER , Replaced By: A3454317076
999
RESERVOIR WITH LOCKING CAP
999
CUP , Replaced By: A3454317186
999
SPRINGTO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
PISTON , Replaced By: A3454317083
999
SPRING , Replaced By: A3454317093
999
PISTON , Replaced By: A3454317183
999
SPRING , Replaced By: A3454317293
999
REPAIR KITTO 001 420 85 18,344 420 71 18
999
REPAIR KITTO 001 420 92 18, NOT USED
999
SNAP RING
999
SNAP RINGTO 001 420 92 18, 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7 NOT USED
999
SEAL RING
999
BRAKE SHOE , Replaced By: A3444207520
999
ELECTRIC CABLE , Replaced By: A3445401361
999
STRAINER
999
FITTING
999
INSPECTION HOLE COVER
999
RIVET
999
BRACKET , NO LONGER AVAILABLE
999
BRAKE SHOE WITH LINING "FRAS-LE"
999
BRAKE SHOE WITH LINING "LONAFLEX"
999
BRAKE SHOE REPAIR SIZE I "LONAFLEX"
999
BRAKE SHOE REPAIR SIZE II "LONAFLEX"
999
BRAKE SHOE WITH LINING "JURID"
999
BRAKE SHOE REPAIR SIZE I "JURID"
999
BRAKE SHOE REPAIR SIZE II "JURID"
999
BRAKE LINING
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"JURID"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"JURID"
999
BRAKE LINING STANDARD 10.4 MM,"FRAS-LE"
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"FRAS-LE"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"FRAS-LE"
999
BRAKE LINING STANDARD 10.4 MM,"LONAFLEX"
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"LONAFLEX"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"LONAFLEX"
999
BRAKE MASTER CYLINDERTEVES, NOT USED
999
DISTRIBUTOR BRAKE MASTER CYLINDER TO 344 430 78 01, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
999
DISTRIBUTOR MASTER CYLINDER TO BRAKE VALVE,548520, 031,032,033,034
999
VALVETO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
WASHERTO 002 430 71 01
999
PISTONTO 002 430 71 01
999
SPRINGTO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
PISTONTO 002 430 71 01
999
CUPTO 002 430 71 01
999
SPRING
999
SPRING
999
PARKING BRAKE
999
BRAKE LINING , Replaced By: A3444210010
999
BRAKE LINING , Replaced By: A3444210110
999
BRAKE LINING , Replaced By: A3444210210
999
INTERMEDIATE PIECE , Replaced By: A3445401561
999
SPRING , Replaced By: A3454317193
999
SPRING
999
SPRING , Replaced By: H983454310793
999
GLAND , Replaced By: A0019901667
999
GLAND , Replaced By: A0019901167
999
SEAL RING LINE CONNECTION
999
SEAL RING BOTTOM
999
UNION NUT
999
UNION NUT
999
UNION NUT LINE MOUNTING
