Поз.
Артикул
Описание
172
172
174
174
174
179
HOSE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
179
HOSE
184
CLAMP LINE TO HOSE
184
LOOM TIE
185
SCREW LINE TO HOSE
186
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
187
CLAMP BREATHER LINE TO REAR AXLE
191
SCREW CABLE TO ALTERNATOR
193
WASHER PLUG SOCKET TO BRACKET
195
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
197
NUT
222
BRAKE HOSE
222
BRAKE HOSE , Replaced By: A0024280735
237
BRACKET. LOCK , Replaced By: A6525040038
238
BRACKET BRAKE HOSE,REAR
239
SCREW PLUG SOCKET TO FRAME
240
LOCK WASHER RAIL TO BATTERY SUPPORT
241
NUT LEVER TO SHIFTING SHAFT
247
LINE , Replaced By: A3444207428
247
LINE FROM MASTER CYLINDER TO CONNECTOR, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
248
LINE FROM CONNECTOR TO REAR AXLE, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
249
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
249
UNION SCREW , Replaced By: A0004280072
257
CONNECTOR OIL DELIVERY LINE
257
CONNECTOR
270
BRAKE HOSE , Replaced By: A0024280735
270
BRAKE HOSE , Replaced By: A0024280735
273
BRACKET. LOCK , Replaced By: A6525040038
274
BRACKET , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
275
SCREW PLUG SOCKET TO FRAME
276
LOCK WASHER RAIL TO BATTERY SUPPORT
277
NUT LEVER TO SHIFTING SHAFT
278
DISTRIBUTOR REAR AXLE
278
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
279
SCREW POWER CYLINDER TO BEARING BRACKET
280
LOCK WASHER RAIL TO BATTERY SUPPORT
281
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
282
UNION SCREW , Replaced By: A0004280072
282
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
283
HOSE BRAKE LINE TO REAR AXLE,4 644238
284
CLAMP BRAKE LINE MOUNTING
285
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
286
LOCK WASHER RAIL TO BATTERY SUPPORT
287
LINE , Replaced By: A3444203728
287
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
288
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
288
UNION SCREW , Replaced By: A0004280072
297
LINE , Replaced By: A3444202728
297
LINE , Replaced By: A3444202828
297
LINE FROM FLUID RESERVOIR TO CONNECTOR 8X0.7 MM, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
297
LINE8X0.7 MM, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
298
UNION NUT LINE CONNECTION
299
FITTING
300
GLAND LINE CONNECTION
301
GROMMET FOR PASSAGE OF LINE
301
GROMMET CABLE THROUGH ELECTRICAL COMPARTMENT,002062 ON VEHICLES HAVING NO MERCEDES-BENZ BODY UP TO IDENT NO. 017956 EXCEPT FOR 017867,017919
302
CONNECTION FITTING ,880809
303
CLAMP
304
SHEET METAL SCREW ELECTRIC CABLE TO FIRE WALL,591820
305
LINE FROM DOUBLE FITTING TO MASTER CYLINDER 8X0.7 MM, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
305
LINE FROM DOUBLE FITTING TO MASTER CYLINDER 8X0.7 MM, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
305
LINE , Replaced By: A3444202928
305
LINE , Replaced By: A3444203028
306
UNION NUT LINE CONNECTION
307
FITTING
308
GLAND LINE CONNECTION
309
CLAMP ,K 147121, Replaced By: N000000000319
309
CLAMP , Replaced By: N916016008200
310
CLAMP
311
BRACKET FUEL LINE
311
BRACKET FUEL LINES
312
SCREW CABLE TO FUSE BOX M 6X12
312
SCREW CABLE TO ALTERNATOR
313
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
314
NUT
999
SPRING
999
PISTON
999
THRUST PIN
999
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
999
HOLLOW SCREW
999
CONNECTOR
999
PROTECTIVE CAP BRAKE BOOSTER
999
WHEEL BRAKE CYLINDER
999
CABLE PULLEYTO 044 420 01 18
999
PROTECTIVE CAP
999
DISTRIBUTOR , Replaced By: A3454287024
999
CONNECTOR BRAKE LINE TO BRAKE MASTER CYLINDER, ONLY ON INSTALLATION OF DIAPHRAGM CYLINDER OF MAKE "WESTINGHOUSE"
999
HOLLOW SCREW AT BRAKE MASTER CYLINDER
999
VALVE , Replaced By: A3454307081
999
FILLER CAP
999
STRAINER , Replaced By: A3084317034
999
WASHER , Replaced By: A3454317076
999
RESERVOIR WITH LOCKING CAP
999
CUP , Replaced By: A3454317186
999
SPRINGTO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
PISTON , Replaced By: A3454317083
999
SPRING , Replaced By: A3454317093
999
PISTON , Replaced By: A3454317183
999
SPRING , Replaced By: A3454317293
999
REPAIR KITTO 001 420 85 18,344 420 71 18
999
REPAIR KITTO 001 420 92 18, NOT USED
999
SNAP RING
999
SNAP RINGTO 001 420 92 18, 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7 NOT USED
999
SEAL RING
999
BRAKE SHOE , Replaced By: A3444207520
999
ELECTRIC CABLE , Replaced By: A3445401361
999
STRAINER
999
FITTING
999
INSPECTION HOLE COVER
999
RIVET
999
BRACKET , NO LONGER AVAILABLE
999
BRAKE SHOE WITH LINING "FRAS-LE"
999
BRAKE SHOE WITH LINING "LONAFLEX"
999
BRAKE SHOE REPAIR SIZE I "LONAFLEX"
999
BRAKE SHOE REPAIR SIZE II "LONAFLEX"
999
BRAKE SHOE WITH LINING "JURID"
999
BRAKE SHOE REPAIR SIZE I "JURID"
999
BRAKE SHOE REPAIR SIZE II "JURID"
999
BRAKE LINING
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"JURID"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"JURID"
999
BRAKE LINING STANDARD 10.4 MM,"FRAS-LE"
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"FRAS-LE"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"FRAS-LE"
999
BRAKE LINING STANDARD 10.4 MM,"LONAFLEX"
999
BRAKE LINING REPAIR SIZE I 11.3 MM,"LONAFLEX"
999
BRAKE LINING REPAIR SIZE II 12.3 MM,"LONAFLEX"
999
BRAKE MASTER CYLINDERTEVES, NOT USED
999
DISTRIBUTOR BRAKE MASTER CYLINDER TO 344 430 78 01, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
999
DISTRIBUTOR MASTER CYLINDER TO BRAKE VALVE,548520, 031,032,033,034
999
VALVETO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
WASHERTO 002 430 71 01
999
PISTONTO 002 430 71 01
999
SPRINGTO 044 430 02 01,A 030543 BM 341.038 USED WITH HYDRAULIC BRAKE,BM 341,041,042,044 UP TO IDENT NO. A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
PISTONTO 002 430 71 01
999
CUPTO 002 430 71 01
999
SPRING
999
SPRING
999
PARKING BRAKE
999
BRAKE LINING , Replaced By: A3444210010
999
BRAKE LINING , Replaced By: A3444210110
999
BRAKE LINING , Replaced By: A3444210210
999
INTERMEDIATE PIECE , Replaced By: A3445401561
999
SPRING , Replaced By: A3454317193
999
SPRING
999
SPRING , Replaced By: H983454310793
999
GLAND , Replaced By: A0019901667
999
GLAND , Replaced By: A0019901167
999
SEAL RING LINE CONNECTION
999
SEAL RING BOTTOM
999
UNION NUT
999
UNION NUT
999
UNION NUT LINE MOUNTING
