Поз.
Артикул
Описание
10
TAKE-UP DEVICE FASTENING FOR JACK, TOP
20
TAKE-UP DEVICE FASTENING FOR JACK, BOTTOM
30
NUT , Replaced By: N913023006001
40
FIXTURE MULTIFUNCTION BOX
40
TAKE-UP DEVICE MULTIFUNCTION BOX, Replaced By: A1698900088
45
BRACKET TAKE-UP DEVICE
50
NUT BRACKET TO BODY SHELL M6
50
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
70
LINING SPARE WHEEL WELL, 9C58QFT169A0109 ANTHRACITE
70
LINING SPARE WHEEL WELL, 9C58QFT169A0109 ANTHRACITE
80
BRACKET SPARE WHEEL
85
BOLT SPARE WHEEL CARRIER
115
PANELING LUGGAGE COMPARTMENT,RIGHT, J 12602120060602807
115
PANELING LUGGAGE COMPARTMENT,LEFT, J 06131120051124806 J 38482220080525809
115
PANELING LUGGAGE COMPARTMENT,LEFT, J 29712620070910808
115
PANELING LUGGAGE COMPARTMENT,RIGHT, J 29712620070910808
120
PANELING LOADING EDGE
120
PANELING LOADING EDGE
120
PANELING LOADING EDGE
120
PANELING LOADING EDGE
125
RIVET PANELING LOAD SILL TO REAR END CENTER ASSEMBLY 13 X 9.2 MM
125
RIVET REAR BODY PANEL,BOTTOM,A 561621I
130
RIVET REAR LID PANELLING TO HINGE BRACKET, NO.9C75
140
CONSOLE LOADING FLOOR,RIGHT
140
CONSOLE LOADING FLOOR,LEFT
150
COVER RIGHT HINGE
150
COVER HINGE,LEFT
160
STAY LOADING FLOOR,REAR
165
COVER STAY
170
BOLT. SCREW CAN NEUTRAL POINT ON EQUIPMENT PLATE M5 X 14
185
COVER LUGGAGE COMPARTMENT
187
RIVET BUSHING AND LEVER TO CAB
190
COVER RIGHT
195
COVER LEFT
197
EXPANSION RIVET. RIVET ATTACHMENT NOISE ENCAPSULATION, ....... I NO.5B22I....... I....... III ....... I .......I....... INO.7D66 III
200
BRACKET MAIN FLOOR FRONT
200
BRACKET REAR FLOOR
205
COVER MAIN FLOOR FRONT
210
BOLT REAR BRACKET MOUNTING M8X22
220
COVER REAR FLOOR TO 169 860 08 14, 9051QFT169A0119 BLACK
225
WASHER P.T.O. TO TRANSMISSION
225
WASHER RADIATOR TO RUBBER MOUNTING
250
ROLLER BLIND TRUNK COVERING, Replaced By: A1698100109
250
COVER LOADING COMPARTMENT
260
LOCKING MECHANISM PARTS KIT, FOR LEFT AND RIGHT
260
LOCKING MECHANISM PARTS KIT, FOR LEFT AND RIGHT, Replaced By: A1696930284
500
BRACKET
505
BRACKET
510
NUT BRACKET TO BODY SHELL M6
515
NUT , Replaced By: N913023006001
600
BRACKET PARTS KIT
610
BOLT CONTACT PLATE FASTENER M5X10
620
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
630
NUT BRACKET TO BODY SHELL M6
