Поз.
Артикул
Описание
10
RADIATOR
10
RADIATOR , Replaced By: A6525016901
10
RADIATOR WATER BEHR
10
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
10
RADIATOR WITH SCREW FITTING,K 115008
10
RADIATOR , Replaced By: A6555000303
10
RADIATOR , Replaced By: A6525014501
10
RADIATOR , Replaced By: A6525014501
10
RADIATOR , Replaced By: A6565001003
10
RADIATOR , Replaced By: A6525016501
10
RADIATOR , Replaced By: A6555003003, +001A6559974582, +001A6559974682
10
RADIATOR
10
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6555002103
10
RADIATOR
10
RADIATOR
10
RADIATOR , Replaced By: A6525014901
10
RADIATOR
10
RADIATOR , Replaced By: A6555000403
10
RADIATOR WITH SCREW FITTING
10
RADIATOR WITH SCREW FITTING
10
RADIATOR
10
RADIATOR , Replaced By: A6525014501
10
RADIATOR , Replaced By: A6525014201
10
RADIATOR ,K 115007
10
RADIATOR WITH SCREW FITTING
15
SCREW WATER DRAIN
20
SCREW PLUG , Replaced By: N007604014101
20
SCREW PLUG WATER DRAIN
25
SEAL RING FUEL LINE TO FEED PUMP
30
LOCK
40
BOOT (SEALING LIP)
40
BOOT (SEALING LIP)
40
BOOT (SEALING LIP)
55
BRACKET SEALING LIP TO RADIATOR
55
BRACKET SEALING LIP TO RADIATOR
55
BRACKET RADIATOR,RIGHT
55
BRACKET SEALING LIP TO RADIATOR
55
BRACKET RADIATOR,LEFT
70
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
70
WASHER , Replaced By: N000125006421
70
WASHER COMPRESSED AIR LINE TO BRACKET
70
SPACER RING , Replaced By: A3059900740
85
SCREW LICENSE PLATE TO BRACKET
85
SCREW , Replaced By: N304017006020
90
SCREW GUIDE TUBE BRACKET TO RADIATOR
100
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
100
WASHER COMPRESSED AIR LINE TO BRACKET
105
NUT , Replaced By: A0009902291
105
NUT RETAINER LICENSE PLATE TO BRACKET
105
NUT RETAINER , Replaced By: A0019906791
115
BRACKET SEALING LIP TO EXPANSION TANK
130
PIN SEALING LIP TO EXPANSION TANK
155
WASHER COMPRESSED AIR LINE TO BRACKET
155
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
160
BRACKET HEATING PIPE,5 405850
160
BRACKET DELIVERY AND SUCTION LINES TO RADIATOR
175
SCREW PUMP TO BRACKET
175
SCREW , Replaced By: N304017006018
175
SCREW , Replaced By: N304017006016
175
SCREW COVER PLATE TO COVER PLATE M 6 X 12
190
WASHER COMPRESSED AIR LINE TO BRACKET
190
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
205
NUT PUMP TO BRACKET
205
NUT , Replaced By: N913004006001
999
RADIATORHAUGG, FROM IDENT NO.4 742813 EXCEPT FOR 4 743433-4 745018,4 745860-4 746037
999
RADIATOR
999
FAN SHROUD RADIATOR
999
PIPE RETURN, OIL COOLER,K 131866
999
PIPE FEED, OIL COOLER,K 131866
999
RADIATOR WATER,5 523343
999
RADIATOR , Replaced By: A6555000303
999
RADIATOR , Replaced By: A6555000303
999
RADIATOR WITH HOSE FITTING,K 096750
999
RADIATOR
999
GUIDE AIR BAFFLE,5 762055
999
GUIDE AIR BAFFLE,5 762056K 009549
999
GUIDE AIR BAFFLE,5 762056K 009549
999
GUIDE AIR BAFFLE,5 762056K 009549
999
RADIATOR , K 031182
