Поз.
Артикул
Описание
5
ELECTRIC CABLE FROM LIGHT SWITCH TO FUSE BOX
10
BASE TIME-LAG RELAY
10
PIN BUSHING HOUSING TIME-LAG RELAY, Replaced By: A0008250518
15
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
15
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
25
PLUG DISTRIBUTOR2.50 MM2
30
LOOM TIE LINE MOUNTING 280 MM
35
DIODE CASE AUXILIARY HEATER
35
DIODE RELAY
40
SCREW CONTROL UNIT TO CAB
45
LOCK WASHER BRACKET TO STEERING COLUMN END
50
NUT IN CASE OF SUBSEQUENT INSTALLATION
50
NUT , Replaced By: N304032005005
55
RELAY APPARATUS PLATE 12V 30 A/WEHRLE
55
RELAY APPARATUS PLATE 12V 30 A/BOSCH
55
RELAY
55
RELAY REAR FOGLAMP
55
RELAY REAR FOGLAMP
60
BRACKET FUSE BOX,748558
65
SCREW CONTROL UNIT TO CAB
70
SERRATED WASHER BRACKET TO SUPPORT
75
NUT IN CASE OF SUBSEQUENT INSTALLATION
75
NUT , Replaced By: N304032005005
80
FUSE BOX APPARATUS PANEL,748558
85
FUSEA16
90
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER
95
SERRATED WASHER FUSE BOX MOUNTING
100
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
103
PLUG DISTRIBUTOR CABLE TO FUSE BOX,712381
105
CABLE HARNESS FROM FUSE BOX TO PULSE SENDER UNIT,809148
105
CABLE HARNESS FROM FUSE BOX TO PULSE SENDER UNIT,809149
105
CABLE HARNESS , Replaced By: A6015400709
108
PIN BUSHING HOUSING TIME-LAG RELAY, Replaced By: A0008250518
108
BASE TIME-LAG RELAY
110
PIN BUSHING HOUSING UNIPOLAR
115
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
120
GROMMET TEMPERATURE GAUGE SENDER UNIT
125
PIN BUSHING HOUSING 6-POLE
126
PIN BUSHING HOUSING 8-POLE
128
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
129
PLUG SOCKET TACHOGRAPH SENDER UNIT CONNECTION
130
SENDER UNIT DAY DRIVING LIGHT 12 V
135
SCREW BRACKET TO COVERING
135
SCREW , Replaced By: N000000001145
140
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
145
NUT SPRING-LOADED PUSH ROD
150
FUSEA8
150
FUSE , Replaced By: N072581008101
155
LOOM TIE LINE MOUNTING 280 MM
999
GROMMET , Replaced By: A3819970881
