Поз.
Артикул
Описание
5
PUMP
8
ELECTRIC MOTOR , Replaced By: A0005402488
11
SHAFT
11
SHAFT , Replaced By: A0005710135
14
CLAMPING PIN2X12 MM
17
PLUG NOT CONFORMING TO DANGEROUS GOODS TRAFFIC REGULATIONS (GGVS)
20
PUMP , Replaced By: A0005715401
23
PUMP , Replaced By: A0005719401
26
RESERVOIR , Replaced By: A0005700204
29
SEAL RING , Replaced By: A0005710780
32
VALVE , Replaced By: A0005711614
35
COVER GREASE FILLING
38
GASKET
41
COVER , Replaced By: A0005711703
44
RETAINING PLATE PUMP VOGEL,TO 000 571 54 01,70 01
47
SCREW , Replaced By: N910143008002
47
SCREW , Replaced By: N304017008016
47
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
50
NUT STRAP TO BRACKET
50
NUT HORN TO BRACKET M8
65
HOSE , ORDER BY THE METER, Replaced By: A0259978682
68
NUT. UNION NUT LINE CONNECTION
71
CUTTING RING. GLAND LINE CONNECTION
74
PIN BUSHING FOR LINE CONNECTION BEKA-MAX , TO 025 997 86 82
74
PIN BUSHING , Replaced By: A0005730753
77
PIN BUSHING , Replaced By: A0005730653
80
INSULATING HOSE HOSE LINE PROTECTION 13 MM, ORDER BY THE METER
83
LOOM TIE TO MOUNT PLASTIC PIPING
83
LOOM TIE TO MOUNT PLASTIC PIPING
86
DISTRIBUTOR , UNTIL PRODUCTION BREAKPOINT DATE 01.09.02
86
DISTRIBUTOR ,236872
86
DISTRIBUTOR , AS OF PRODUCTION BREAKPOINT DATE 02.09.02236871
89
SCREW , WITH DIESEL ENGINE
92
WASHER COVERING TO CAB
95
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
101
FITTING LINE CONNECTION VOGEL
104
SEAL CONE LINE CONNECTION VOGEL
107
ELBOW LINE CONNECTIONS VOGEL, M 10X1
107
ELBOW , Replaced By: A0005733530
116
FITTING , Replaced By: A0009974334
119
SEAL CONE , Replaced By: A0019909567
999
FITTING , UNTIL PRODUCTION BREAKPOINT DATE 01.09.02
999
CONNECTOR , UNTIL PRODUCTION BREAKPOINT DATE 01.09.02
999
GUIDE SLEEVE , UNTIL PRODUCTION BREAKPOINT DATE 01.09.02
