Поз.
Артикул
Описание
2
RADIATOR , Replaced By: A0005001103
2
RADIATOR WATER,5 337827
6
TANK EXPANSION TANK
6
TANK ON RADIATOR
12
RADIATOR CAP CENTRAL
12
RADIATOR CAP CENTRAL
16
RADIATOR CAP FILLER NECK
16
RADIATOR CAP FILLER NECK
17
GASKET O.D., 52 MM
18
GASKET O.D., 37 MM
19
SCREW PLUG , Replaced By: N007604014101
19
SCREW PLUG WATER DRAIN
20
SEAL RING FUEL LINE TO FEED PUMP
21
HOSE OVERFLOW, EXPANSION TANK
24
CLAMP , Replaced By: N916017011001
24
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
36
SCREW , Replaced By: N304017008016
36
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
37
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
38
WASHER , Replaced By: N000125008443
38
WASHER EXHAUST MUFFLER TO STRAP
39
BRACKET , NOT USED
40
SCREW COVER PLATE TO BRACKET
41
SPRING WASHER LICENSE PLATE TO BRACKET
42
SCREW CLAMP TO BRACKET AND TO PIPE
43
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
44
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
47
TANK (EXPANSION TANK)
52
RADIATOR CAP
53
GASKET O.D., 37 MM
54
DRAIN PIPE EXPANSION TANK
56
DRAIN PIPE
60
HOSE OVERFLOW
61
CLIP CABLE HARNESS TO ROOF RAIL
62
BRACKET EXPANSION TANK
66
BRACKET EXPANSION TANK
72
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
76
WASHER COMPRESSED AIR LINE TO BRACKET
76
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
78
STRAP EXPANSION TANK TO BRACKET
82
STRAP EXPANSION TANK TO BRACKET
86
SHIM EXPANSION TANK TO BRACKET
90
SHIM EXPANSION TANK TO BRACKET
96
SCREW CLAMP MOUNTING M 6X16
96
SCREW , Replaced By: N000000001146
100
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
104
WASHER , Replaced By: N009021006208
104
WASHER COMPRESSED AIR LINE TO BRACKET
118
BOOT RADIATOR
119
BRACKET BOOT
120
WASHER , Replaced By: N000125006421
120
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
120
WASHER COMPRESSED AIR LINE TO BRACKET
121
SPRING WASHER LICENSE PLATE TO BRACKET
122
SCREW , Replaced By: N304017006020
122
SCREW LICENSE PLATE TO BRACKET
999
RADIATOR , Replaced By: A0005019001
999
RADIATOR , Replaced By: A0015010201
999
CLAMP , Replaced By: N916017011000
999
HOSE , Replaced By: A0219977682
999
HOSE , Replaced By: A0139978682
999
HOSE
999
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
999
GASKET , Replaced By: A4422010480
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 121160, Replaced By: A4220100240
999
TANK ,5 129372, Replaced By: A6205000349, +001A6205012882, +001N916017020000
999
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6205001672
999
LINE ,5 188037 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 275405, Replaced By: A6205002872, +002A6205062035
999
LINE , Replaced By: A6205002872
999
LINE , Replaced By: A6205003072
999
CONNECTOR , Replaced By: A6205010323
999
PIPE ELBOW AT WATER PUMP,5 193594
999
CONNECTOR , Replaced By: A6205010423
999
PIPE ELBOW , Replaced By: A6205010556
999
PIPE ELBOW , Replaced By: A6555010756
999
HOSE , Replaced By: A6205012882
999
HOSE , Replaced By: A6555011282
999
RUBBER MOUNTING , Replaced By: A6205040112
999
SPACER RING , Replaced By: A3059900740
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW , Replaced By: A4609900601
