Поз.
Артикул
Описание
110
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
532
VALVE (RELAY VALVE) KNORR
532
VALVE (RELAY VALVE) BOSCH
532
VALVE (RELAY VALVE) WABCO
534
VALVE (RELAY VALVE) GRAU
536
SEAL RING22.3X2.4 MM,GRAU
538
VALVE SEATGRAU
540
SEAL RINGTO 000 429 28 95,GRAU
542
SEAL RING28X2 MM,GRAU
544
SEAL RING86X2 MM,GRAU
546
GASKET34X2X6 MM,GRAU
548
REPAIR KITWABCO
550
VALVEBOSCH
550
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
550
REPAIR KIT , Replaced By: A0004201071
552
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
552
REPAIR KIT , Replaced By: A0004301109
554
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
556
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
558
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
560
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
562
THRUST RING CHECK VALVE TO AIR RESERVOIR
562
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
564
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
566
O-RING CHECK VALVE TO AIR RESERVOIR
568
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
570
BRACKET RELAY VALVE,5 484806
574
BRACKET RELAY VALVE, NOT USED
576
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
576
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
576
NUT , Replaced By: N913004008001
580
SCREW BRACKET TO SIDE MEMBER
580
SCREW , Replaced By: N304017010002
582
NUT STRAP TO BRACKET
582
NUT , Replaced By: N910113010000
696
NUT BRACKET TO SIDE MEMBER
706
FITTING LEFT AND RIGHT BRAKE HOSES
999
GUIDE , Replaced By: N071752014000
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
CUPTO 008 420 97 18, 008 420 90 18, BOSCH
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
MUFFLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 95 18, 008 420 97 18, BOSCH
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KIT SEAL RING BOSCH,209
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGM , Replaced By: A0004314128
999
VALVEWABCO
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
CONNECTOR REPAIR SIZE
999
BUSHING , Replaced By: N915062009000
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUGTO 009 420 22 18,008 420 20 18
999
PLUG
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
PROTECTIVE CAPKNORR
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
REPAIR KIT SPRING LOAD ACCUMULATOR CYLINDER TO 008 420 20 18,KNORR
999
SEAL RINGKNORR
999
ADHESIVE FOIL GUIDE SIGN
999
BRAKE HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
FITTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
YOKETO 008 420 95 18,008 420 97 18,BOSCH
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
