Поз.
Артикул
Описание
444
CONSOLE CAB MOUNTING,FRONT
448
BOW CAB MOUNTING,FRONT
452
STRUT BUMPER,LEFT
452
STRUT BUMPER,RIGHT
456
WASHER SHOCK ABSORBER TO UPPER BEARING BRACKET
458
SCREW , Replaced By: A9429901304
458
SCREW APPARATUS SUPPORT TO FRAME
460
SCREW , Replaced By: N308676014012
460
SCREW SUPPORT TO SIDE MEMBER M 14X45
462
NUT , Replaced By: N910113014000
462
NUT STEERING SUPPORT TO FRAME
464
SCREWM 16X18X26X48
466
NUT , Replaced By: N910113016001
466
NUT CONSOLE TO SUPPORT
470
BRACKET LEFT BUFFER
470
BRACKET RIGHT BUFFER
474
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
476
WASHER SPARE WHEEL CARRIER
478
NUT , Replaced By: N910113014001
478
NUT BRACKET TO SIDE MEMBER
482
MOUNTING (RUBBER BUFFER)
484
SCREW , Replaced By: N304017008034
484
SCREW BRACKET TO CROSS CONNECTION STRUT
486
WASHER , Replaced By: N009021008213
486
WASHER BRACKET TO LEFT SIDE MEMBER
488
NUT , Replaced By: N913004008001
488
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
488
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
492
MOUNTING CAB SUSPENSION,FRONT LEFT
492
MOUNTING CAB SUSPENSION,FRONT RIGHT
496
SPRING CAB SUSPENSION,FRONT
500
BUSHING SPRING
504
GREASE NIPPLE FOR SPRING
508
LEVER (TILTING LEVER),CAB
512
BUSHING TILTING LEVER
512
BUSHING TILTING LEVER
516
BUFFER TILTING LEVER
530
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
534
HEADLESS SETSCREW FOR SPRING
538
MOUNTING CAB TILTING LEVER
542
SCREW END PIECE TO EXHAUST PIPE M 10X25
544
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
546
SCREW , Replaced By: N308676012012
546
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
546
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
548
LOCK WASHER FITTING TO BRACKET
552
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
552
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
556
RUBBER MOUNTING
560
BUSHING
562
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
562
WASHER VIBRATION ABSORBER TO BEARING AND TO CAB
564
WASHER , Replaced By: N000125013008
564
WASHER
566
NUT SUPPORT TO SIDE MEMBER
574
WASHER STABILIZER TO BEARING
578
STABILIZER , Replaced By: A6558900004
578
STABILIZER CAB SUSPENSION,FRONT, USED WITH MERCEDES-BENZ MEDIUM-LENGTH/LONG/LARGE-CAPACITY CABS
582
JOINT BEARING , Replaced By: A0009817231
582
JOINT BEARING , Replaced By: A0019814631
582
JOINT BEARING
586
GREASE NIPPLE FOR SPRING
590
SCREW PLUG STABILIZER
598
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
598
MOUNTING SPRING AND STABILIZER,LEFT
598
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
598
MOUNTING SPRING AND STABILIZER,RIGHT
602
PIN
604
SCREW , Replaced By: N304017008034
604
SCREW BRACKET TO CROSS CONNECTION STRUT
606
NUT , Replaced By: N913004008001
606
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
606
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
608
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
610
SCREW , Replaced By: N000961014084
610
SCREW , Replaced By: N000961014148
610
SCREW FRONT SPRING REAR BRACKET TO SIDE MEMBER M 14X1.5X75
612
WASHER SPARE WHEEL CARRIER
614
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
616
NUT , Replaced By: N910113014001
616
NUT BRACKET TO SIDE MEMBER
620
CONSOLE , Replaced By: A6208910631
620
CONSOLE CAB SUSPENSION,FRONT LEFT
620
CONSOLE , Replaced By: A6208910731
620
CONSOLE CAB SUSPENSION,FRONT RIGHT
624
SCREW , Replaced By: N308676012015
624
SCREW LEFT AND RIGHT CONSOLES TO CAB
626
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
628
LOCK WASHER FITTING TO BRACKET
630
WASHER LEFT AND RIGHT CONSOLES TO CAB
632
SCREW , Replaced By: N308676014020
632
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
634
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
638
SHIM MOUNTING TO CONSOLE
638
SHIM , Replaced By: A3878910498
640
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
640
SCREW , Replaced By: N308676014003
642
SCREW MOUNTING TO SIDE MEMBER M 14X85
644
HEXAGON HEAD BOLT. SCREW SUPPORT TO SIDE MEMBER M 14X100
644
SCREW , Replaced By: N308765014008
646
WASHER SPARE WHEEL CARRIER
650
NUT STEERING SUPPORT TO FRAME
650
NUT , Replaced By: N910113014000
654
BUFFER (HOLLOW RUBBER SPRING),CAB
658
FLANGE HOLLOW RUBBER SPRING
662
BUSHING HOLLOW RUBBER SPRING
663
WASHER HOLLOW RUBBER SPRING TO CAB,5 956657
663
WASHER , Replaced By: A4432610076
664
SCREW BRACKET TO SIDE MEMBER
664
SCREW , Replaced By: N304017010002
999
SCREWM 16X17X28X48
999
JOINT BEARING
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
SCREW , Replaced By: N308676012013
999
SCREW , Replaced By: A3959900501
999
SCREW , Replaced By: A0029908201
999
PIN PULL TO FASTENER
999
RIVET BUSHING AND LEVER TO CAB
999
SCREWM 14X14X17X35
999
SCREW , Replaced By: A3169900014
999
SCREWM 14X14X22X40
999
SCREWM 14X14X18X32
999
SCREWM 14X14X27X45
999
SCREWM 16X18X18X40
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
SCREWM 12X13X18X35
999
SCREWM 12X14X13X35
999
SCREWM 14X14X24X42
999
SCREWM 14X15X15X32
999
SCREWM 14X15X21X38
999
SCREW PLATE TO SIDE MEMBER
999
SCREWM 16X17X22X42
999
SCREWM 12X13X21X38
999
SCREWM 14X15X27X44
999
SCREWM 14X15X17X34
999
SCREWM 14X15X29X46
999
SCREWM 14X15X19X36
999
SCREWM 12X13X15X32
999
SCREW , Replaced By: A0009906314
999
SCREWM 14X14X32X50
999
SCREWM 12X13X35X52
999
SCREWM 14X15X35X52
999
SCREWM 14X15X31X48
999
SCREWM 10X11X26.5X46
999
SCREWM 12X12X10X25
999
SCREW , Replaced By: A3229903101
999
SCREW , Replaced By: N308676016020
999
SCREWM 16X16X22X40
999
SCREW , Replaced By: N000961016118
999
SCREWM 12X12X11X26
999
SCREWM 12X12X13X28
999
SCREWM 16X16X20X38
999
SCREWM 16X16X30X48
999
SCREWM 16X16X32X50
999
SCREWM 14X14X18X34
999
SCREWM 12X12X15X30
999
SCREWM 12X12X17X32
999
SCREWM 18X18X23X45
999
SCREW , Replaced By: N000961018043
999
CROSS MEMBERNO.5A
999
CROSS MEMBERNO.3A
999
STRUT LEFT AND RIGHT
999
STRUT LEFT AND RIGHT
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
999
RUBBER BUFFER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3893250117
999
SCREWM 16X18X63X85
999
SCREWM 16X16X20X45
999
SCREWM 12X13X13X30
999
SCREWM 12X13X23X40
999
SCREWM 12X13X12X29
999
SCREWM 16X18X38X60
999
SCREWM 12X13X25X42
999
SCREWM 16X16X38X90
999
SCREWM 14X15X18X35
999
SCREWM 16X17X24X44
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
SCREWM 12X13X63X85
999
SCREWM 12X13X58X80
999
FITTED SCREWM 10X11X14X28
999
FITTED SCREWM 10X11X24X40
999
FITTED SCREWM 18X19X57X85
999
FITTED SCREWM 10X11X25X38
999
FITTED SCREWM 18X19X25X45
999
FITTED SCREWM 18X19X38X60
999
FITTED SCREWM 18X19X33X55
999
SCREW STABILIZER TO BEARING
999
SCREW SHOCK ABSORBER TO BOTTOM BRACKET M 16X85
999
SCREWM 16X16X24X42
999
SCREWM 18X18X33X55
999
HEXAGON HEAD BOLT , Replaced By: A0029902704
999
SCREW CONSOLE TO FRAME
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
LOCK PULL TO FASTENER
999
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
NUT , Replaced By: N910113012003
999
NUT TORSION BAR TO BEARING BRACKET,5 904661
