Поз.
Артикул
Описание
39
COVERING CHASSIS
39
ANTINOISE CAPSULE CHASSIS
39
ANTINOISE CAPSULE CHASSIS
42
SUPPORT CHASSIS
42
COVERING CHASSIS,5 736351
42
COVERING CHASSIS,5 736351
42
COVERING CHASSIS,5 736350
42
COVERING CHASSIS,5 736351
42
COVERING CHASSIS,5 736351
42
COVERING CHASSIS
42
COVERING CHASSIS,5 736351
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
48
SCREW PUMP TO BRACKET
48
SCREW , Replaced By: N304017006016
48
SCREW END PIECE TO EXHAUST PIPE M 10X25
49
WASHER RADIATOR TO RUBBER MOUNTING
49
WASHER , Replaced By: N000125010532
50
NUT , Replaced By: N910113010000
50
NUT STRAP TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COVERING TO CAB
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET
88
BRACKET LEFT FENDER
88
BRACKET RIGHT FENDER
96
SCREW END PIECE TO EXHAUST PIPE M 10X25
96
SCREW , Replaced By: N304017008018
96
SCREW SUPPORT TO FENDER
100
WASHER , Replaced By: N000125010532
100
WASHER RADIATOR TO RUBBER MOUNTING
100
WASHER , Replaced By: N009021008213
100
WASHER BRACKET TO LEFT SIDE MEMBER
104
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
104
NUT , Replaced By: N913004008001
104
NUT STRAP TO BRACKET
104
NUT , Replaced By: N910113010000
108
BRACKET FENDER
108
BRACKET FENDER
108
BRACKET FENDER
108
BRACKET FENDER
112
SCREW BRACKET TO CROSS CONNECTION STRUT
112
SCREW BRACKET TO CROSS CONNECTION STRUT
112
SCREW , Replaced By: N304017008034
116
WASHER EXHAUST MUFFLER TO STRAP
116
WASHER EXHAUST MUFFLER TO STRAP
116
WASHER , Replaced By: N000125008443
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
NUT , Replaced By: N913004008001
124
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
124
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
128
SCREW REAR EXHAUST PIPE TO MUFFLER
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
128
SCREW , Replaced By: N304017008027
132
WASHER EXHAUST MUFFLER TO STRAP
132
WASHER RADIATOR TO RUBBER MOUNTING
132
WASHER , Replaced By: N000125010532
132
WASHER EXHAUST MUFFLER TO STRAP
132
WASHER , Replaced By: N000125008443
136
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
NUT STRAP TO BRACKET
136
NUT , Replaced By: N910113010000
136
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
NUT , Replaced By: N913004008001
152
MOUNTING ANGLE RIGHT
152
MOUNTING ANGLE LEFT
192
MOUNTING ANGLE COVERING, TO BE ADAPTED DURING ASSEMBLY
192
MOUNTING ANGLE , Replaced By: A6205240210
192
MOUNTING ANGLE COVERING, TO BE ADAPTED DURING ASSEMBLY
192
MOUNTING ANGLE , Replaced By: A6205240210
200
SCREW BRACKET TO CROSS CONNECTION STRUT
200
SCREW BRACKET TO CROSS CONNECTION STRUT
200
SCREW , Replaced By: N304017008034
204
WASHER BRACKET TO LEFT SIDE MEMBER
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER BRACKET TO LEFT SIDE MEMBER
204
WASHER , Replaced By: N009021008213
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER , Replaced By: N000125008443
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT , Replaced By: N913004008001
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET COVERING
244
BRACKET , Replaced By: A6555240040
244
BRACKET , Replaced By: A6555240040
244
BRACKET COVERING,5 736351
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET , Replaced By: A6735460243
244
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
244
BRACKET LEFT
244
BRACKET COVERING
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET , Replaced By: A6205240340
248
BRACKET COVERING
248
BRACKET COVERING
250
BRACKET COVERING
252
SCREW REAR EXHAUST PIPE TO MUFFLER
252
SCREW REAR EXHAUST PIPE TO MUFFLER
252
SCREW REAR EXHAUST PIPE TO MUFFLER
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
256
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
256
SCREW REAR EXHAUST PIPE TO MUFFLER
256
SCREW END PIECE TO EXHAUST PIPE M 10X25
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER BRACKET TO FRAME
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER RADIATOR TO RUBBER MOUNTING
260
WASHER , Replaced By: N000125010532
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT STRAP TO BRACKET
264
NUT , Replaced By: N910113010000
264
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
264
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
264
NUT , Replaced By: N913004008001
268
SCREW PIPE CLAMP
268
SCREW , Replaced By: N304017008021
272
WASHER EXHAUST MUFFLER TO STRAP
272
WASHER , Replaced By: N000125008443
276
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
276
NUT , Replaced By: N913004008001
376
ANTINOISE CAPSULE CHASSIS,5 385158
376
ANTINOISE CAPSULE CHASSIS,5 385157
378
COVERING RIGHT, NOT USED
378
COVERING LEFT, NOT USED
388
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
388
BRACKET , Replaced By: A3604292940
388
BRACKET , Replaced By: A3184923641
388
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
388
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
388
BRACKET , Replaced By: A3184923441
396
SCREW PIPE CLAMP
396
SCREW PIPE CLAMP
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW REDUCTION VALVE TO BRACKET
396
SCREW , Replaced By: A0079900801
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW PIPE CLAMP
396
SCREW PIPE CLAMP
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW BRACKET TO CROSS CONNECTION STRUT
396
SCREW , Replaced By: N304017008034
396
SCREW SUPPORT TO FENDER
396
SCREW , Replaced By: N304017008018
396
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
396
SCREW , Replaced By: N304017008016
396
SCREW PIPE CLAMP
396
SCREW , Replaced By: N304017008021
404
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
404
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
404
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
404
NUT , Replaced By: N913004008001
408
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 5 592740, Replaced By: A6204290168
408
BRACKET COVERING
412
SCREW BRACKET TO SIDE MEMBER
412
SCREW , Replaced By: N304017010002
412
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
412
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
412
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
412
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
420
WASHER RADIATOR TO RUBBER MOUNTING
420
WASHER RADIATOR TO RUBBER MOUNTING
420
WASHER RADIATOR TO RUBBER MOUNTING
420
WASHER RADIATOR TO RUBBER MOUNTING
420
WASHER , Replaced By: N000125010532
428
NUT STRAP TO BRACKET
428
NUT STRAP TO BRACKET
428
NUT STRAP TO BRACKET
428
NUT STRAP TO BRACKET
428
NUT , Replaced By: N910113010000
492
COVERING REAR
499
SEAL , Replaced By: A6455240492
499
SEAL COVER PLATE, TO BE ADAPTED DURING ASSEMBLY
