Поз.
Артикул
Описание
222
CYLINDER , Replaced By: A0005537505
222
CYLINDER , Replaced By: A0015534605
222
CYLINDER POWER CYLINDER, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
225
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
228
SEAL RING PISTON TO 000 553 46 05,4 359587
228
SEAL RING PISTON TO 000 553 46 05,4 359587
231
BOOT GUIDE TO 000 553 46 05,4 359587
231
BOOT GUIDE TO 000 553 46 05,4 359587
234
SEAL RINGTO 000 553 46 05,4 359587
237
SEAL CONE HYDRAULIC LINE TO 000 553 46 05,4 359587
240
SCREW HYDRAULIC LINE TO 000 553 46 05,4 359587
240
NUT HIGH PRESSURE HOSE TO HYDRAULIC CYLINDER TO 000 553 46 05,000 553 51 05, 387.002-154, 389.002-154, UP TO CHASSIS 4 646673, 387.212-294, 389.213,223, 391.310,320,393.311-587, 395.312-472 UP TO CHASSIS 4 646483
246
GLAND , Replaced By: A0019901667
246
SEAL CONE
249
SEAL RINGTO 000 553 03 05,000 553 18 05,
252
SCREW PLUG , Replaced By: N000908014009
252
SCREW PLUGTO 000 553 03 05,000 553 18 05,
255
GUIDEWEBER,TO 001 553 45 05
255
GUIDEWEBER,TO 000 553 75 05, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
258
REPAIR KIT , Replaced By: A0005500107
258
GASKET KIT , Replaced By: A0005500507
258
GASKET KIT HYDRAULIC CYLINDER WEBER,TO 000 553 75 05, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
258
GASKET KIT HYDRAULIC CYLINDER WEBER,TO 000 553 87 05
261
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
261
PUMP (HAND PUMP) WEBER
265
PISTON , Replaced By: A0005531990
265
PISTONWEBER,TO 000 553 40 01
265
PISTONTO 000 553 79 01,WEBER
268
VALVETO 000 553 88 01
268
VALVEWEBER,TO 000 553 40 01
268
VALVETO 000 553 79 01,WEBER
271
SCREW , Replaced By: N000000000190
271
SCREW
274
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
277
FILTER
280
FITTED WASHER
283
LOCK RING
286
SCREW , Replaced By: A0009901310
286
SCREW OIL FILLING TO 000 553 89 01
286
SCREW
289
GASKET KIT HAND PUMP
289
GASKET KIT HAND PUMP
292
SCREW REAR EXHAUST PIPE TO MUFFLER
999
PIN , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
MOUNTING SPRING AND STABILIZER,RIGHT
999
MOUNTING SPRING AND STABILIZER,LEFT
999
STABILIZER , Replaced By: A6528900104
999
CONSOLE CAB SUSPENSION,FRONT RIGHT
999
CONSOLE CAB SUSPENSION,FRONT LEFT
999
LEVER CAB LOCKING MECHANISM
999
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
999
MOUNTING CAB TILTING LEVER
999
BUSHING TILTING LEVER
999
MOUNTING RIGHT VIBRATION ABSORBER
999
MOUNTING LEFT VIBRATION ABSORBER
999
MOUNTING CAB, RIGHT
999
MOUNTING CAB,LEFT
999
MOUNTING , Replaced By: A6558910420
999
MOUNTING , Replaced By: A6558910320
999
MOUNTING CAB SUSPENSION,FRONT RIGHT, ON VEHICLES LESS DB CAB 10/20 UP TO IDENT NO. 4 358957, 50/60 UP TO IDENT NO. 4 362764
999
MOUNTING CAB SUSPENSION,FRONT LEFT, ON VEHICLES LESS DB CAB4 358957
999
MOUNTING LEFT SIDE MEMBER
999
LEVER (TILTING LEVER),CAB
999
LEVER (TILTING LEVER),CAB
999
WASHER , Replaced By: A4432610076
999
WASHER STABILIZER TO BEARING
999
BRACKET BUFFER
999
SHIM , Replaced By: A3878910498
999
SHIM MOUNTING TO CONSOLE
999
SPACER TUBE VIBRATION ABSORBER TO CONSOLE
999
SPACER TUBE MOUNTING TO CONSOLE
999
SPRING , Replaced By: A3878910551, +002A3638910617, +001N071412008200
999
RAIL , Replaced By: A3878901222
999
ADHESIVE FOIL GUIDE SIGN
999
BEARING BRACKET HYDRAULIC CYLINDER
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
STRUT BUMPER AT TORSION BAR
999
WASHER BEARING BRACKET
999
WASHER , Replaced By: N000125013008
999
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
999
STRUT BUMPER,RIGHT
999
STRUT BUMPER,LEFT
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
BUSHING HOLLOW RUBBER SPRING
999
BUFFER (HOLLOW RUBBER SPRING),CAB
999
FLANGE HOLLOW RUBBER SPRING
999
BUFFER TILTING LEVER
999
MOUNTING (RUBBER BUFFER)
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
CYLINDER , Replaced By: A0015534205, +001A0005537901
999
PUMP (HAND PUMP) POWER PACKER,4 733732
999
PUMP , Replaced By: A0005536501
999
PUMP , Replaced By: A0005536801
