Поз.
Артикул
Описание
113
LINE (PRESSURE HOSE),FROM DISCONNECTING POINT,ENGINE,TO HIGH-PRESSURE HOSE KREIS II
113
LINE FROM PUMP TO HIGH PRESSURE HOSE, CIRCUIT I
113
LINE FROM PUMP TO HIGH PRESSURE HOSE, CIRCUIT I,5 9048065 959804
113
LINE (PRESSURE HOSE),FROM DISCONNECTING POINT,ENGINE,TO HIGH-PRESSURE HOSE
116
LINE (DELIVERY LINE),FROM PUMP TO HOSE, CIRCUIT I
119
UNION NUT LINE CONNECTION
122
UNION NUT LINE CONNECTION, Replaced By: N000000006239
122
UNION NUT LINE CONNECTION
125
GLAND LINE CONNECTION
128
GLAND , Replaced By: A0019901967
128
SEAL CONE LINE CONNECTION
131
T-FITTING POWER STEERING
131
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
131
T-FITTING SUPPLY LINE FOR TRANSMISSION
131
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
131
FITTING , Replaced By: N003952015100
131
FITTING OIL LINE CONNECTION
131
FITTING (PARTS KIT),LINE RUPTURE
131
FITTING DELIVERY LINE TO PUMP
131
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
132
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
132
HOSE STEERING GEAR DELIVERY LINE,CIRCUIT I, Replaced By: A0229976682
132
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
132
HIGH-PRESSURE HOSE (DELIVERY LINE),FROM PUMP TO STEERING
137
LINE FROM PRESSURE LIMIT VALVE TO STEERING, CIRCUIT II,K 061656
137
LINE FROM PRESSURE LIMIT VALVE TO STEERING, CIRCUIT II
160
HOSE , NOT USED
161
HOSE , Replaced By: A6254660281
161
HOSE , Replaced By: A6254660281
161
HOSE FROM RETURN LINE TO OIL TANK
170
LINE (RETURN LINE) FROM HOSE TO HOSE,CIRCUIT: 1,5 904805
170
LINE (RETURN LINE) FROM HOSE TO HOSE,CIRCUIT: I
170
LINE (RETURN LINE),FROM HOSE TO HOSE KREIS I
173
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
173
CLAMP HOSE TO FITTING AND TO OIL TANK
173
CLAMP , Replaced By: N000000000667
173
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
182
LINE FROM STEERING TO PRESSURE LIMIT VALVE T-FITTING,CIRCUIT II
182
LINE RETURN, STEERING TO T-PIECE, FLOW DISPLAY
185
LINE (RETURN LINE) FROM FLOW INDICATOR TO HOSE
185
LINE (RETURN LINE) FROM FLOW INDICATOR TO HOSE KREIS II
185
LINE (RETURN LINE) FROM FLOW INDICATOR TO HOSE KREIS II
185
LINE (RETURN LINE) FROM FLOW INDICATOR TO HOSE
185
LINE RETURN LINE,PRESSURE LIMIT VALVE, CIRCUIT II
191
LINE (RETURN LINE) FROM HOSE TO HOSE,CIRCUIT: 2,5 904805
191
LINE (RETURN LINE),FROM HOSE TO HOSE KREIS II
191
LINE (RETURN LINE) FROM HOSE TO HOSE,CIRCUIT: 2,5 9048065 959804
194
UNION NUT LINE CONNECTION
197
GLAND LINE CONNECTION
368
BRACKET OIL LINE TO TRANSMISSION CASE
371
SCREW , Replaced By: N304017008021
371
SCREW PIPE CLAMP
374
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
481
BRACKET OIL LINE TO ENGINE
485
BRACKET BRACKET TO STARTING MOTOR
488
BRACKET COOLING WATER LINE
490
BRACKET RETURN LINE TO ENGINE
512
BRACKET LINE TO REAR TRANSMISSION CASE,5 537500
514
BRACKET OIL LINE TO TRANSMISSION
515
BRACKET PRESSURE ACCUMULATOR
517
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
518
SCREW EXHAUST PIPE TO BRACKET
557
CLAMP FEED LINE TO THERMOSTAT
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
557
CLAMP LINE MOUNTING
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
557
CLAMP , Replaced By: A6739950001
557
CLAMP DELIVERY AND SUCTION LINES TO STEERING
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
560
CLAMP LINES TO BRACKET
560
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
560
CLAMP DELIVERY AND SUCTION LINES TO FRAME
560
CLAMP LINE MOUNTING
560
CLAMP OIL FILLER PIPE TO BRACKET
560
CLAMP OIL DIPSTICK TO RADIATOR
560
CLAMP HOSE TO FLANGE AND TO VALVE
560
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
563
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
563
CLAMP HOSE TO FITTING AND TO OIL TANK
563
CLAMP , Replaced By: N000000000667
563
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
566
CLAMP LINE MOUNTING
566
CLAMP HOSE ON AIR COMPRESSOR SUCTION LINE,V 225942
566
SPACER. CLAMP
581
SCREW COVER PLATE TO BRACKET
581
SCREW , Replaced By: N304017006018
581
SCREW , Replaced By: N304017006020
581
SCREW , Replaced By: N304017006016
581
SCREW PUMP TO BRACKET
581
SCREW COVER PLATE TO COVER PLATE M 6 X 12
581
SCREW CAB FLOOR COVERING M 6X25
581
SCREW LICENSE PLATE TO BRACKET
581
SCREW BRACKET ON LOAD SENSOR
587
SCREW , Replaced By: N304017012022
593
NUT PUMP TO BRACKET
593
NUT , Replaced By: N913004006001
596
LOOM TIE LINE MOUNTING
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
999
BRACKET POWER CYLINDER DELIVERY LINE,5 556098
999
BRACKET OIL LINE TO LEFT FRAME SIDE MEMBER, FRONT,K 130661
