Поз.
Артикул
Описание
65
DASHPOT
68
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
71
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
77
HEXAGON HEAD BOLT
83
NUT HORN TO BRACKET M8
95
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
98
NUT ENGINE MOUNTING M8
104
CLAMP , Replaced By: N071555124501
107
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
197
206
SENDER UNIT TEMPERATURE SENSOR,EXHAUST
266
269
272
SCREWM 10X20
275
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
278
281
284
287
290
SCREW BRACKET TO SIDE MEMBER M10X35
293
296
299
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
302
CONSOLE EXHAUST MUFFLER
305
DAMPING PAD EXHAUST MUFFLER SUSPENSION
311
SCREW BRACKET TO CAB REAR PANEL M 8X20
314
317
320
323
PROTECTIVE PLATE
326
NUT BRACKET TO FIRE WALL
329
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
332
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 16X25
335
BUFFER
338
341
344
347
350
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
353
NUT , Replaced By: N913023010002
359
362
365
368
371
374
CLAMP I.D., 104,5MM
377
380
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
383
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
386
BRACKET
389
