Поз.
Артикул
Описание
98
WATERFILTER
104
FILTER
107
SEAL RINGTO A 000 832 20 72, Replaced By: A0018358398
110
SCREW. HEXAGON HEAD BOLT LINE MOUNTING M6X90
122
125
MOUNTING CLAMP22/15
125
CLAMP38/20
125
CLAMP60/25
125
MOUNTING CLAMP W SHACKLE SUCTION/DELIVERY/RETURN LINES 58/20MM
125
CLAMP48/20
125
MOUNTING CLAMP28/15
128
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
128
CLAMP HOSE TO INTAKE MANIFOLD 25-40X13MM,V 207570
128
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
128
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
128
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
131
SCREW , Replaced By: N910143008000
131
SCREW BRACKET AND CLAMP M6X20
131
SCREW BRACKET TO CAB REAR PANEL M 8X20
131
SCREW , Replaced By: N914146006102
131
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
134
NUT HORN TO BRACKET M8
134
NUT BRACKET TO FIRE WALL
134
NUT RELAY TO BRACKET M5
164
164
167
167
170
170
173
176
176
179
SEAL RING
179
SEALING RING. SEAL RING OIL DRAIN
182
185
188
191
HOSE22X31X100MM
194
HOSE38X50X80MM
194
HOSE ,D 209702
194
HOSE28X37X80MM, TO BE ADAPTED DURING ASSEMBLY, Replaced By: N000000004982
200
203
SERVO-D.C. W.GEARBOX
206
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
209
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
211
WASHER ATTACHMENT OF ELECTRIC LEAD AND GROUND STRAP ON ALTERNATOR
217
MOLDED HOSE 90-DEGREE ARC D38
229
232
238
241
VALVE
244
SEAL RING
246
SPACER
247
262
265
MOLDED HOSE 90-DEGREE ARC D22
268
MOLDED HOSE AT RESERVOIR,BOTTOM D28MM
316
319
322
999
WARNING SIGN , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.01.2011
999
