Поз.
Артикул
Описание
5
BATTERY12 V/100 AH
5
BATTERY FILLED AND CHARGED 12V/220AH
5
BATTERY FILLED AND CHARGED 12V/170AH
5
BATTERY12 V/165 AH
5
BATTERY , Replaced By: A0045415101
5
BATTERY FILLED AND CHARGED 12V/200AH
5
BATTERY FILLED AND CHARGED 12V/180AH
5
BATTERY , Replaced By: A0035418801
5
BATTERY12 V/135 AH
5
BATTERY12 V/115 AH
5
BATTERY12V/120 AH
8
BATTERY SUPPORT APPARATUS
11
BRACKET BATTERY/APPARATUS SUPPORT,RIGHT
11
BRACKET BATTERY/APPARATUS SUPPORT,LEFT
14
SCREW , Replaced By: N304017006020
14
SCREW LICENSE PLATE TO BRACKET
17
NUT PUMP TO BRACKET
17
NUT , Replaced By: N913004006001
20
FASTENING CLAMP BATTERY/APPARATUS SUPPORT
20
LOCKING HANDLE BATTERY/APPARATUS SUPPORT, Replaced By: A9609880142
23
RIVET LOCKING LEVER TO BATTERY/APPARATUS SUPPORT
26
SCREW BRACKET TO CAB CONSOLE,K 035197
26
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
32
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
32
WASHER SPARE WHEEL CARRIER
32
WASHER , Replaced By: N000125015019
35
NUT , Replaced By: N910113014001
35
NUT BRACKET TO SIDE MEMBER
38
COVER BATTERY/APPARATUS SUPPORT
41
BATTERY CASE
44
RAIL. BATTERY BASE FRAME
47
SCREW BRACKET TO FRAME SIDE MEMBER
50
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
53
INSULATING PLATE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
56
WASHER , Replaced By: N007349010007
56
WASHER STRUT TO CROSS MEMBER
59
NUT STRAP TO BRACKET
59
NUT , Replaced By: N910113010000
62
MOUNTING FRAME BATTERY MOUNTING
65
SCREW BATTERY MOUNTING M 8X260X40
65
SCREW BATTERY MOUNTING
68
WASHER , Replaced By: N009021008213
68
WASHER BRACKET TO LEFT SIDE MEMBER
71
BRACKET BATTERY MOUNTING,5 928008 FROM IDENT NO. 5 928009 SEE SA 46975
74
SPACER TUBE BATTERY MOUNTING,5 928008 FROM IDENT NO. 5 928009 SEE SA 46975
80
STOP BATTERY MOUNTING
999
BLIND CAPTO A 004 541 48 01
999
WASHER , Replaced By: N009021010209
999
WASHER BRACKET TO COVERING
