Поз.
Артикул
Описание
8
RUBBER MOUNTING FRONT
8
RUBBER MOUNTING FRONT
11
STOP ENGINE FRONT MOUNTING TO 653 241 00 13,356 240 00 17
14
NUT SUPPORT TO SIDE MEMBER
17
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X38
20
WASHER CONSOLE TO FRAME
50
BEARING BRACKET LEFT AND RIGHT
56
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
56
SCREW , Replaced By: N308676012011
56
SCREW SUPPORT TO SIDE MEMBER
56
SCREW , Replaced By: N000961012025
56
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
56
SCREW , Replaced By: N308676012026
59
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
62
LOCK WASHER FITTING TO BRACKET
65
NUT SUPPORT TO SIDE MEMBER
74
SUPPORTING ARM REAR
83
SCREW SUPPORTING ARM TO BELL HOUSING M 18X60
83
SCREW , Replaced By: N308676018009
86
WASHER ENGINE MOUNTING TO SUPPORTING ARM
92
RUBBER MOUNTING REAR
92
RUBBER MOUNTING REAR
92
RUBBER MOUNTING REAR
98
SCREENING PLATE REAR RUBBER MOUNTING
104
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X60
107
WASHER CONSOLE TO FRAME
113
SUPPORT REAR RUBBER MOUNTING, TO BE ADAPTED DURING ASSEMBLY
119
REINFORCEMENT SUPPORT TO SIDE MEMBER
122
SCREW APPARATUS SUPPORT TO FRAME
122
SCREW , Replaced By: A9429901304
122
SCREW MOUNTING TO CONSOLE M 14X35
122
SCREW , Replaced By: N308676014008
128
NUT STEERING SUPPORT TO FRAME
128
NUT , Replaced By: N910113014000
131
RIVET REAR CROSS MEMBER 12X42 MM
131
RIVET REINFORCEMENT TO SIDE MEMBER
134
SCREW CONSOLE TO SIDE MEMBER
134
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
134
SCREW , Replaced By: N308676012026
137
WASHER
