Поз.
Артикул
Описание
5
BRAKE VALVE (SERVICE BRAKE VALVE) GRAU
5
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
5
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE VALVEKNORR
5
BRAKE VALVEGRAU
5
BRAKE VALVEBOSCH
5
BRAKE VALVEWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
6
REPAIR KIT , Replaced By: A0004308506
6
REPAIR KIT"WABCO"
6
REPAIR KIT , Replaced By: A0004308406
8
WASHER EXHAUST MUFFLER TO STRAP
8
WASHER , Replaced By: N000125008443
11
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
11
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
11
NUT , Replaced By: N913004008001
14
HOSE BRAKE VALVE,CONNECTION: "30"
17
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW , Replaced By: A0009973734
23
VALVE (REDUCTION VALVE)
26
VALVE (PRESSURE LIMIT VALVE)
29
FITTING SHUTTLE VALVE
32
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
35
FITTING LINE CONNECTION
38
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
41
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
53
SCREW. UNION SCREW LINE CONNECTION
999
REPAIR KIT SERVICE BRAKE VALVE WABCO
