Поз.
Артикул
Описание
8
ELECTRIC CABLE FROM EMERGENCY "OFF" SWITCH TO FUSES, RELAYS,BATTERY MASTER SWITCH & CAB
8
ELECTRIC CABLE FROM EMERGENCY "OFF" SWITCH TO FUSES, RELAYS,BATTERY MASTER SWITCH & CAB
12
ELECTRIC CABLE , Replaced By: A6785400036
16
RELAY , Replaced By: A0035459605
16
RELAY , Replaced By: A0035459605
16
RELAY , Replaced By: A0035459605
16
RELAYA33
16
RELAYA33, Replaced By: A0009822123
20
RELAYA32/K6
24
RELAY ENGINE SHUT-OFF,K 037933
28
RELAY. TIME-LAG RELAY , Replaced By: A0035457805
30
DIODE
32
SWITCH (BATTERY MASTER SWITCH)
36
SCREW , Replaced By: N304017008021
40
NUT , Replaced By: N913004008001
44
GASKET BATTERY MASTER SWITCH,5 584018
48
BOOT BATTERY MASTER SWITCH,5 584018
52
CLAMP CABLE HARNESS MOUNTING
56
SCREW BOOT
60
SCREW REFLECTOR TO BRACKET
64
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
64
SCREW , Replaced By: N007985005157
68
LOCK WASHER T-FITTING TO BRACKET
72
LOCK WASHER FITTING TO BRACKET
72
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
76
WASHER BOOT TO CAB FLOOR
76
WASHER , Replaced By: N000433005304
80
NUT TACHOGRAPH TO BRACKET
84
NUT STRAP TO SUPPORT,5 149419
84
NUT BRACKET TO SUPPORT AND TO END PIECE
88
SWITCH EXHAUST BRAKE,K 004388
88
SWITCH , Replaced By: A0045450314, +001A0005465435
92
NUT SUCTION LINE TO OIL PUMP
100
SERRATED WASHER EXHAUST BRAKE FOOT-OPERATED SWITCH
104
WASHER EXHAUST BRAKE FOOT-OPERATED SWITCH
999
RELAY , Replaced By: A0035459605
999
SPRING WASHER AT CAB FLOOR
