Поз.
Артикул
Описание
5
BRAKE VALVEWABCO
5
BRAKE VALVEKNORR
5
BRAKE VALVEBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
REPAIR KITWABCO
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH, Replaced By: A0004303506
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH
8
REPAIR KIT , Replaced By: A0004308306
11
NUT , Replaced By: N913004008004
11
NUT , Replaced By: N913004008001
14
HOSE BRAKE VALVE,CONNECTION: "30"
17
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW , Replaced By: A0009973734
23
DISTRIBUTOR LESS CHECK VALVE
32
GUIDE BUSHING TWO-WAY VALVE TO FRAME
32
GUIDE BUSHING TWO-WAY VALVE TO FRAME
32
SPACER TUBE , Replaced By: A3094310249
35
SCREW VALVE TO CAB M 8X85
44
NUT , Replaced By: N913004008001
47
SCREW. UNION SCREW LINE CONNECTION
53
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
53
VALVE (RELAY VALVE) BOSCH
53
VALVE (RELAY VALVE) KNORR
53
VALVE (RELAY VALVE) GRAU
53
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
53
VALVE (RELAY VALVE) WABCO
59
VALVE SEATGRAU
62
GASKET34X2X6 MM,GRAU
65
SEAL RING22.3X2.4 MM,GRAU
68
SEAL RING28X2 MM,GRAU
71
SEAL RINGTO 000 429 28 95,GRAU
74
SEAL RING86X2 MM,GRAU
77
REPAIR KITWABCO
77
REPAIR KITKNORR
77
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
77
REPAIR KIT , Replaced By: A0004301109
80
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
80
REPAIR KIT , Replaced By: A0004201071
80
VALVEBOSCH
86
WASHER EXHAUST MUFFLER TO STRAP
86
WASHER , Replaced By: N000125008443
89
NUT , Replaced By: N913004008001
92
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
93
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
94
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
95
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
95
THRUST RING CHECK VALVE TO AIR RESERVOIR
98
O-RING CHECK VALVE TO AIR RESERVOIR
107
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
107
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
