Поз.
Артикул
Описание
24
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
24
CLUTCH PRESSURE PLATE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 155611, Replaced By: A0032502604
24
CLUTCH PRESSURE PLATE , Replaced By: A0032502604
24
CLUTCH PRESSURE PLATE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 850353, Replaced By: A0032507004
26
SPRING SUSPENDED BELOW LEAF SPRING
26
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
27
CLAMP , Replaced By: A0002523227
27
CLAMP RELEASE FLANGE TO RELEASE LEVER
29
RELEASE LEVER CLUTCH ACTUATION
30
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
31
SPINDLE FOR BRACKETS
31
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
31
SPINDLE , Replaced By: A0002522816, +001A1249945241
31
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
32
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
33
BRACKET RELEASE LEVER
33
BRACKET FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
34
LOCK PLATE LEVER TO BRACKET
34
LOCK PLATE RELEASE LEVER TO SHAFT
35
FLANGE CLUTCH PRESSURE PLATE
35
FLANGE , Replaced By: A0002521245
36
SPRING , Replaced By: A0002523227
36
SPRING SUSPENDED BELOW LEAF SPRING
36
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
37
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
37
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
38
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
38
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
39
NUT , Replaced By: A0002523072
39
NUT FOR BRACKETS
40
LOCK FOR BRACKETS
41
LOCK WASHER BRACKET TO STEERING COLUMN END
42
SCREW RELEASE LEVER,BRACKET
42
SCREW JUNCTION BOX TO REAR CROSS MEMBER
43
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
44
SCREW CLUTCH TO FLYWHEEL
45
CLUTCH DISC ASBESTOS-FREE LINING
45
CLUTCH DISC , Replaced By: A0052500103
45
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0092504503
45
CLUTCH DISC , Replaced By: A0062508703
46
LEAF SPRING
46
LEAF SPRING , Replaced By: A0002523319
46
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
47
RIVET , Replaced By: A0002522075
47
RIVET LEAF SPRING TO CLUTCH DISC
47
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
49
CLUTCH LINING , Replaced By: A0012522010
49
CLUTCH LINING , Replaced By: A0012528310
49
CLUTCH LINING , Replaced By: A0022520010
49
CLUTCH LINING ASBESTOS-FREE
50
RIVET , Replaced By: A0002523375
50
RIVET , Replaced By: A0002523775
50
RIVET , Replaced By: A0002524675
50
RIVET , Replaced By: A0002524875
50
RIVET LINING WITH CLUTCH DISC
51
RIVET LINING WITH CLUTCH DISC
51
RIVET , Replaced By: A0002524875
999
PLUG BELL HOUSING
999
INSULATING WASHER
999
SLEEVE CLUTCH PRESSURE PLATE
999
HOUSING
999
PRESSURE PLATE
999
PRESSURE PLATE , ON ELIMINATION OF INSULATING WASHER 000 252 00 24, Replaced By: A0002524912
999
HOUSING
999
PRESSURE PLATE CLUTCH PRESSURE PLATE
999
LOCK
999
PIN CLUTCH SLAVE CYLINDER,006538
999
VALVE , Replaced By: A3075530107
999
CLUTCH LINING
999
WASHER , Replaced By: A3094310051
999
LEVER CLUTCH ACTUATION,4 601610
999
VALVE CLUTCH SLAVE CYLINDER
999
SPACER RING BRACKET TO TRANSMISSION,5 215322
999
WASHER AS REQUIRED 0.90 MM
999
WASHER AS REQUIRED 1.10 MM
999
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
999
REPAIR KIT , Replaced By: A3892500014
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW MOUNTING AND RAIL TO LEAF SPRING
999
SCREW , Replaced By: N308676018010
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
BALL SOCKET CLUTCH SLAVE CYLINDER, UP TO IDENT NO. 007219 ALSO INSTALLED ON 007228-007232,007241-007243,007245,007646,007254
999
SECURING CLIP , Replaced By: N073130019300
999
SNAP RING CLUTCH SLAVE CYLINDER
999
LOCK WASHER BELL HOUSING TO TRANSMISSION
