Поз.
Артикул
Описание
5
TAIL LAMP RIGHT "R & S"
5
TAIL LAMP RIGHT "HELLA"
5
TAIL LAMP LEFT "R & S"
5
TAIL LAMP , Replaced By: A0025440203
8
LENS''R&S''
8
LENS''HELLA''
11
GASKETHELLA
11
GASKETR&S
14
BRACKET TAIL LAMP
14
BRACKET LEFT TAIL LAMP
17
COVERING AT TAIL LAMP BRACKET
20
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
23
NUT , Replaced By: N304032008006
26
SCREW , Replaced By: N304017010002
26
SCREW REAR EXHAUST PIPE TO MUFFLER
29
NUT , Replaced By: N910113010000
32
BRACKET REFLECTOR
35
SCREW OIL DELIVERY LINE TO BRACKET
38
WASHER , Replaced By: N009021006208
41
NUT , Replaced By: N913004006001
44
REFLECTOR
47
SCREW REFLECTOR TO BRACKET
50
WASHER , Replaced By: N000433005304
53
NUT TWO-WAY VALVE TO BRACKET
56
NAME PLATE
59
SUPPORT
62
RIVET NAME PLATE TO TAIL LAMP BRACKET
65
SCREW CLAMP TO BRACKET AND TO PIPE
68
NUT , Replaced By: N913004008001
71
SCREW , Replaced By: N007985006580
74
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
77
NUT , Replaced By: N913004006001
