Поз.
Артикул
Описание
1
BATTERY , Replaced By: A0035410101
1
BATTERY , Replaced By: A0035411801
1
BATTERY , Replaced By: A0025412301
1
BATTERY12 V/135 AH
2
FRAME BATTERY MOUNTING, 10/20 UP TO CHASSIS 4 347 646,50/60 UP TO CHASSIS 4 345 731
2
MOUNTING FRAME BATTERY MOUNTING, 10/20 FROM CHASSIS 4 347 647,50/60 FROM CHASSIS 4 345 732
3
CLAMPING SCREW BATTERY MOUNTING 190 MM, 415 5 014668 416 5 000515 417 4 972023
3
CLAMPING SCREW BATTERY MOUNTING
4
NUT BALL PIVOT TO LEVER
6
SUPPORT BATTERY/APPARATUS SUPPORT
7
WASHER , Replaced By: N000125015019
7
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
8
SCREW BRACKET TO CAB CONSOLE,K 035197
8
SCREW AT CROSS MEMBER
9
NUT , Replaced By: N910113014001
9
NUT BRACKET TO SIDE MEMBER
12
RAIL BATTERY BASE FRAME, 415 5 014668 416 5 000515 417 4 972023
13
INSULATING PLATE , Replaced By: A3855410236
13
INSULATING PLATE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
13
INSULATING PLATE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
14
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
15
SCREW BRACKET TO FRAME SIDE MEMBER
16
WASHER , Replaced By: N007349010007
16
WASHER STRUT TO CROSS MEMBER
17
NUT , Replaced By: N910113010000
17
NUT STRAP TO BRACKET
18
BATTERY CASE , 9746764 194385
18
BATTERY CASE (BATTERY TRAY)
19
PROTECTIVE PLATE BATTERY SUPPORT
23
SWITCH , Replaced By: A0005458408
23
SWITCH (BATTERY MASTER SWITCH)
24
SCREW CAB FLOOR COVERING M 6X25
25
NUT , Replaced By: N913004006001
25
NUT PUMP TO BRACKET
26
LOCK WASHER T-FITTING TO BRACKET
26
SPRING WASHER ALTERNATOR CONNECTION D+
26
SPRING WASHER LICENSE PLATE TO BRACKET
27
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
34
GROUND STRAP , Replaced By: A3145400041
34
GROUND STRAP , Replaced By: A3525400041
34
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
34
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
35
NEG. CABLE , Replaced By: A6205402339
35
NEG. CABLE FROM FRAME CROSS MEMBER TO CAB
36
GROMMET5.0 MM
999
BULB , Replaced By: N072601024704
999
BULB WITH REINFORCED COILED FILAMENT 24 V/10 W
999
BULB TELL-TALE LAMP
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW BRACKET TO SIDE MEMBER
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
RIVET NAME PLATE TO TAIL LAMP BRACKET
999
NUT SUPPORT TO SIDE MEMBER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER FITTING TO BRACKET
999
NUT ALTERNATOR CONNECTION
999
NUT , Replaced By: N913002006009
999
NUT OIL TANK TO BRACKET
999
NUT TWO-WAY VALVE TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
ELECTRIC CABLE , Replaced By: A6735460013
999
SCREW MANUAL PUMP TO BRACKET AND TO PLATE M 10X40
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW , Replaced By: N308676012012
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO TAIL LAMP BRACKET,5 453766
999
TOOTHED WASHER ELECTRIC CABLE TO FUSE BOX
999
TOOTHED WASHER STOP LIGHT SWITCH TO PEDAL BEARING BRACKET
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SHEET METAL SCREW SETSCREW LEAD-SEALING IN TACHOGRAPH
999
SHEET METAL SCREW BUZZER TO CAB,4 374617
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SCREW REFLECTOR TO BRACKET
999
SCREW JUNCTION BOX TO BRACKET
999
SCREW , Replaced By: N000000001146
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER , Replaced By: N009021010209
999
WASHER BRACKET TO COVERING
999
CABLE SHOE BATTERY CABLE 10-70 MM
999
CABLE SHOE BATTERY CABLE 12-70 MM
999
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
999
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
999
ELECTRIC CABLE , Replaced By: N922002070000
999
BULB , Replaced By: N072601024192
999
BULB TAIL LAMP 21 W
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008021
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW DISTRIBUTOR TO CAB
999
SCREW , Replaced By: N304017006020
999
SCREW CONNECTOR
999
WASHER BOOT TO CAB FLOOR
999
WASHER
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000433005304
999
COTTER PIN ROD TO INTERMEDIATE LEVER
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SCREW CLAMP MOUNTING M 6X16
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
999
CABLE HARNESS RIGHT TAIL LAMP
999
GROMMET ELECTRIC CABLE TO BRACKET
999
CAP TO PLUG THE FREE BORES IN INSTRUMENT PANEL,5 220080
999
BRACKET HORN,K 082848
999
ELECTRIC CABLE FROM DOOR PLUG CONNECTION TO OUTSIDE REARVIEW MIRROR PLUG-CONNECTION,4 849449
999
CABLE HARNESS TAIL LAMP
999
CABLE HARNESS , Replaced By: A6215402207
999
CABLE HARNESS , Replaced By: A6175401507
999
CABLE HARNESS , Replaced By: A6175400207
999
ELECTRIC CABLE FROM TACHOGRAPH TO PULSE TRANSMITTER
999
ELECTRIC CABLE , Replaced By: A6155401336
999
ELECTRIC CABLE , Replaced By: A6155400736
999
ELECTRIC CABLE , Replaced By: A6155400736
999
BOOT
999
GROMMET
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
999
ELECTRIC CABLE IDLING SWITCH BRANCH-OFF EXTENSION
999
CAP TO PLUG THE FREE BORES IN INSTRUMENT PANEL,5 220080
999
SUPPORT
999
BRACKET , Replaced By: A3875401773
999
BRACKET , Replaced By: A3875401873
999
BRACKET , Replaced By: A3875401773
999
GROMMET JUNCTION BOX BRANCH-OFF
999
WASHER TAIL LAMP TO SUPPORT
999
ADAPTER RATIO:
999
ADAPTER SPEEDOMETER,4 895865
999
ADAPTER RATIO: 1:0.903
999
BRACKET ,K 082848, Replaced By: A6205420840
999
BRACKET FLEXIBLE SHAFT TO BUMPER SUPPORT
999
BRACKET
999
CLAMPING SCREW , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 277658, Replaced By: A3875410424
999
ELECTRIC CABLE , Replaced By: A3815401227
999
ELECTRIC CABLE FROM CHASSIS/CAB TO FRONT LONGITUDINAL DIFFERENTIAL LOCK CONTROL,5 1802665 220080
999
ELECTRIC CABLE , Replaced By: A3805400281
999
ELECTRIC CABLE INDUCTIVE PICKUP
999
ELECTRIC CABLE GEAR DISPLAY,4 3032554 315081
999
ELECTRIC CABLE ,4 231689
999
BRACKET HORN
999
BRACKET ELECTRIC CABLE TENSILE STRESS RELIEF
999
CABLE HARNESS , Replaced By: A3875403405
999
RAIL , Replaced By: A3875400818
999
ELECTRIC CABLE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 196046, Replaced By: A3875400232
999
GROUND STRAP , Replaced By: A3145400041
999
ELECTRIC CABLE , Replaced By: A3895401737
999
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
999
POS.CABLE , Replaced By: N072551070880, +001N072332013100, +001N072332013200
999
CABLE HARNESS , Replaced By: A3875400205
999
BRACKET PROTECTIVE PLATE TO APPARATUS SUPPORT, 415 5 014668 416 5 000515 417 4 972023
999
BRACKET , Replaced By: A3874260040
999
GROMMET , Replaced By: A0089976381
999
RING WARNING INDICATOR
999
BLIND CAP TACHOGRAPH, 4 109008
999
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO ALTERNATOR,4 483482
999
GROMMET
999
GROMMET ,5 180265
999
PLUG SOCKET PRESSURE SWITCH SCREW-CONNECTION TO M 24X1
999
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 27X1
999
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
999
PLUG SOCKET , Replaced By: A3805402281
999
PLUG SOCKET , Replaced By: A3805402181
999
INTERMEDIATE PIECE
999
BRACKET , Replaced By: A3875401773
999
POS.CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
999
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
999
POS.CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
999
POS.CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
999
SUPPORT , Replaced By: A3875840051
999
METAL SECTION , Replaced By: A0019877625
999
BRACKET , Replaced By: A3525405273, +001A3525440538, +002N000125006421, +001N000965006023, +001N007985006176, +002N913002006005
999
BRACKET , Replaced By: A3525405173, +001A3525440538, +002N000125006421, +001N000965006023, +001N007985006176, +002N913002006005
999
BRACKET TAIL LAMP,5 453766
999
BRACKET JUNCTION BOX
999
BRACKET JUNCTION BOX
999
ELECTRIC CABLE , Replaced By: A0018207015, +001A6209970481
999
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
999
HOOD FASTENER BATTERY CASE,RB037929
999
PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
999
WASHER
999
RESISTOR GEAR CLUSTER INDICATOR RELAY,MAIN CABLE HARNESS 1.0 W
999
GROMMET ENGINE COMPARTMENT LAMP
