Поз.
Артикул
Описание
80
SHIFT LEVER ,4 291252
80
SHIFT LEVER ,4 291252
80
SHIFT LEVER , Replaced By: A3892606039
81
SHIFT LEVER
85
BUSHING PAWL TO ROD END,5 443047
85
BUSHING , Replaced By: A3359920203
91
JOINT BEARING SHIFT LEVER BEARING,K040603
91
JOINT BEARING SHIFT LEVER BEARING,K040603
91
JOINT BEARING , Replaced By: A0019813931
96
PIN ,4 116950, Replaced By: A3852681474, +001A3892605262, +001A3892680440
96
LOCK RING SHIFT LEVER BEARING
101
PIN SHIFT LEVER BEARING,K040603
106
BRACKET ,4 116950, Replaced By: A3892605262, +001A3892680440, +001A3852681474
106
BOOT SHIFT LEVER BEARING
106
BOOT , Replaced By: A6202680196
111
BRACKET SHIFT LEVER LOWER PART,K040603
116
BRACKET SHIFT LEVER UPPER PART,K040603
116
BRACKET , Replaced By: A3892680440
116
BRACKET ,4 116950, Replaced By: A3892680440, +001A3892605262, +001A3852681474
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
NUT , Replaced By: N913004008001
125
VALVE (SHIFT LEVER VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
125
VALVE , Replaced By: A3852600057
128
HOSE (PARTS KIT),4 411810
128
HOSE , Replaced By: A3019971182
128
HOSE , Replaced By: A3019970682
128
HOSE , Replaced By: A3019970682
128
HOSE , Replaced By: A3019970682
129
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
129
SHIFT LEVER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6202680042, +001A6202680157
130
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
130
CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6202680157
131
HANDLE SHIFT LEVER
133
HANDLE SHIFT LEVER
133
HANDLE , Replaced By: A3432600040
133
HANDLE (GEARSHIFT LEVER KNOB)
136
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
141
COVER SHIFT LEVER
146
DECALCOMANIA NINE-SPEED
146
DECALCOMANIA NINE-SPEED,SHIFT LEVER KNOB
148
GUMMED LABEL NINE-SPEED,ASHTRAY,4 947402
148
GUMMED LABEL NINE-SPEED,ASHTRAY,5 032516
151
SHIFTING ROD (TELESCOPIC SHIFTING ROD),4 291252
151
SHIFTING ROD (TELESCOPIC SHIFTING ROD),4 112115
153
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
153
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
154
SHIFTING TUBE (TELESCOPIC TUBE)
154
SHIFTING ROD (TELESCOPIC TUBE)
155
PULL ROD
156
SPRING MECHANICAL RELAESE,4 291252
157
YOKE MECHANICAL RELAESE,4 291252
158
ROD END HYDRAULIC RELEASE
159
PAWL MECHANICAL RELAESE,4 291252
160
PAWL SHIFTING ROD,5 443048
160
PAWL ,5 4430475 443048, Replaced By: A6202600087, +001A6202680150
161
BUSHING PAWL TO ROD END,5 443047
162
SPRING ROD END
163
SPRING ROD END
164
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
165
SCREW SHIFTING ROD TO SHIFT LEVER
165
SCREW , Replaced By: N000933010192
166
NUT STRAP TO BRACKET
166
NUT , Replaced By: N910113010000
167
ROUND CORD RING. SEAL RING ROD END
167
SEAL RING , Replaced By: A0009978648
170
SEAL RING HYDRAULIC RELEASE
171
SEAL RING8.30 MM,4 291252
172
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
172
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
173
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
174
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
174
PIN , Replaced By: N001444008235
175
SPRING WASHER SHIFTING CYLINDER TO YOKE
176
WASHER BETWEEN THE SHIFTING RODS
178
SHIFTING ROD REAR,4 817018
178
SHIFTING ROD REAR,4 291252
180
SHIFTING ROD REAR,4 855703
180
SHIFTING ROD REAR,4 291252
193
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
198
SCREW CONNECTOR TO REAR SHIFTING ROD
198
SCREW , Replaced By: N304017010047
199
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
204
NUT STRAP TO BRACKET
204
NUT , Replaced By: N910113010000
206
SHIFTING ROD SHIFTING SHAFT
206
SHIFTING ROD SHIFTING SHAFT
208
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
212
ROUND CORD RING. SEAL RING ROD END
212
SEAL RING , Replaced By: A0009978648
216
SCREW SHIFTING ROD TO SHIFT LEVER
216
SCREW , Replaced By: N000933010192
220
NUT STRAP TO BRACKET
220
NUT , Replaced By: N910113010000
223
SCREW BRACKET TO CROSS CONNECTION STRUT
223
SCREW , Replaced By: N304017008034
223
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
223
SCREW , Replaced By: N304017008027
225
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
225
NUT , Replaced By: N913004008001
230
RUBBER PAD SHIFT LEVER TO CAB FLOOR,K040603
230
RUBBER PAD ,4 105160, Replaced By: A3852680392, +004A3892680525, +002A3852680492
234
TUBE. BUSHING CAB FLOOR COVERING
234
TUBE GEARSHIFT LEVER LOWER PART,4 105160
235
BRACKET GEARSHIFT LEVER UPPER PART,4 291252
236
BRACKET BOOT
238
BRACKET GEARSHIFT LEVER LOWER PART,4 291252
240
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
242
RUBBER PAD SHIFT LEVER BEARING TO CAB FLOOR
242
RUBBER PAD ,4 105160, Replaced By: A3852680492, +004A3892680525, +001A3852680392
244
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
244
NUT , Replaced By: N913004008001
245
SCREW SUPPORT TO FENDER
245
SCREW , Replaced By: N304017008018
248
RUBBER RING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3852681950
249
BUSHING SHIFT LEVER BEARING TO CAB FLOOR
255
BOOT SHIFTING LEVER
257
BRACKET LINE MOUNTING,4 411811
257
BRACKET , Replaced By: A3892600262
257
BRACKET LINE MOUNTING,4 411811
259
SERRATED WASHER BRACKET TO CAB FLOOR,4 411811
260
NUT BALL PIVOT TO LEVER
270
SLEEVE LINE MOUNTING
274
UNION NUT LINE MOUNTING, Replaced By: N000000006521
278
GLAND LINE MOUNTING
999
HOLLOW SCREW , Replaced By: N915047008100
999
BANJO UNION , Replaced By: N915052006013
999
REPAIR KIT SHIFT LEVER VALVE
999
T-FITTING EXHAUST-BRAKE POWER CYLINDER
999
SEAL RING OUTSIDE WABCO
999
FITTING , Replaced By: A0039979072
999
LOOM TIE , Replaced By: A0019978390
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
FITTING (PARTS KIT),LINE RUPTURE
999
TS DOUBLE FITTING SOLENOID VALVE
999
FITTING , Replaced By: A0029905971
999
FITTING , Replaced By: A0029906071
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SEAL RING ,4 411810
999
SEAL RING PISTON RINGS WABCO
999
SEAL RING SCREW FITTING WABCO
999
SHAFT SHIFTING TUBE TO TRANSMISSION
999
BUSHING PAWL TO ROD END,5 443048
999
BUSHING PAWL TO ROD END,5 443048
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING LINE CONNECTION
999
SHEET METAL SCREW
999
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
999
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
999
HOLLOW SCREW LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
