Поз.
Артикул
Описание
8
BEARING TUBE CONTROL SHAFT
8
BEARING TUBE
8
BEARING BRACKET , Replaced By: A4420701319
8
BEARING BRACKET
8
BEARING BRACKET CONTROL SHAFT
24
BUSHING MOUNTING
40
SHAFT ,460462
43
SHAFT CONTROL
55
BALL PIVOT
55
BALL PIVOT , Replaced By: A3129910120
55
BALL PIVOT LEVER
56
SEAL RING MODULATION PRESSURE CONTROL
58
NUT HEATING PIPE TO BRACKET
59
COVERING
72
LEVER
72
LEVER , Replaced By: A4420701321
88
HUB
88
BUSHING MOUNTING
104
BALL PIVOT , Replaced By: A3129910120
104
BALL PIVOT LEVER
120
LEVER CONTROL SHAFT
120
LEVER , Replaced By: A4420701521
120
LEVER CONTROL SHAFT
126
LEVER CONTROL SHAFT
136
BALL PIVOT LEVER
136
BALL PIVOT
136
BALL PIVOT
136
BALL PIVOT , Replaced By: A3129910120
136
BALL PIVOT
138
LEVER INJECTION PUMP CONTROL
138
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420705921
138
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 590957, Replaced By: A4420702521
138
LEVER LOAD CONTROL, TO BE ADAPTED DURING ASSEMBLY
139
SEAL RING MODULATION PRESSURE CONTROL
140
NUT WINDOW REGULATOR TO REAR DOOR
140
NUT HEATING PIPE TO BRACKET
141
BALL PIVOT
141
BALL PIVOT LEVER
141
BALL PIVOT , Replaced By: A3129910120
142
SCREW BEARING BRACKET TO TRANSMISSION
142
HEXAGON HEAD BOLT
143
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
155
WOODRUFF KEY
168
HEXAGON HEAD BOLT. SCREW STARTER SWITCH TO STEERING COLUMN JACKET TUBE
184
NUT HEATING PIPE TO BRACKET
184
NUT BALL PIVOT TO LEVER
200
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
216
SPRING CONTROL SHAFT LEVER ASSEMBLY TO CONTROL SHAFT
216
SPRING
216
SPRING , Replaced By: A4429935110
216
SPRING , Replaced By: A4429935010
232
BUSHING
248
CYLINDER (OPERATING CYLINDER),918799
248
CYLINDER INJECTION PUMP CONTROL
248
CYLINDER (OPERATING CYLINDER)
248
CYLINDER , 364 021703 366 061186, Replaced By: A0000721512, +001A3649910322, +001N900071008100
248
CYLINDER , Replaced By: A0000721512
248
CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0000720512, +001A4420720624
248
CYLINDER , NOT USED
248
CYLINDER (OPERATING CYLINDER)
248
CYLINDER (OPERATING CYLINDER)
250
REPAIR KIT (POWER CYLINDER)
280
ROD , Replaced By: A3660720324
280
ROD CYLINDER
280
ROD
280
ROD CYLINDER, 401-403 266368 421-423 177788 442 007644
280
ROD AT CONTROL LEVER
280
ROD CYLINDER,851619
280
ROD CYLINDER
280
ROD
280
ROD CYLINDER
280
ROD CYLINDER
280
ROD CYLINDER
280
ROD CYLINDER
285
PULL ROD BRACKET TO FRAME
285
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
287
ROD CYLINDER
287
ROD ,424-010666
287
ROD , Replaced By: A3660720324
296
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
296
BALL SOCKET ,266368
296
BALL SOCKET , 364 021704 366 061187
296
BALL SOCKET
298
LEVER CYLINDER
300
BALL PIVOT
306
SEAL RING MODULATION PRESSURE CONTROL
312
NUT BALL PIVOT TO LEVER
312
NUT
312
NUT
312
NUT , Replaced By: N304035008001
312
NUT , Replaced By: A0009900851
312
NUT AT SHIFT LEVER
320
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
322
SCREW CLAMP MOUNTING M 6X16
323
NUT BALL PIVOT TO LEVER
324
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
325
LEVER OPERATING CYLINDER TO CONTROL SHAFT LEVER
346
LEVER
346
LEVER (CONTROL LEVER),INJECTION PUMP
348
LEVER INJECTION PUMP CONTROL
348
LEVER , Replaced By: A4030704921
348
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420705921
376
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 671974, Replaced By: A4420703021
376
LEVER LOAD CONTROL, TO BE ADAPTED DURING ASSEMBLY
376
LEVER INJECTION PUMP CONTROL
388
SEAL RING MODULATION PRESSURE CONTROL
391
BALL PIVOT , Replaced By: N071803010102
391
BALL PIVOT
391
BALL PIVOT LEVER
391
BALL PIVOT , Replaced By: A3129910120
392
WASHER COVERING TO CAB
392
WASHER HEAT SHIELD TO BRACKET
393
NUT HEATING PIPE TO BRACKET
393
NUT WINDOW REGULATOR TO REAR DOOR
395
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
395
PULL ROD
398
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
401
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
404
NUT BALL PIVOT TO LEVER
408
HEXAGON HEAD BOLT
408
SCREW CLAMP MOUNTING M 6X16
410
HEXAGON HEAD BOLT
410
SCREW BEARING BRACKET TO TRANSMISSION
424
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
430
BRACKET CYLINDER CRANKCASE
434
BALL PIVOT , Replaced By: N071803010102
438
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
442
NUT BALL PIVOT TO LEVER
456
SCREW SUPPORTING ARM TO HOUSING M 16X35
456
SCREWM 10X20
456
SCREW BRACKET WITH FUEL FILTER TO ENGINE
456
SCREW BEARING BRACKET TO CYLINDER CRANKCASE
456
SCREW BRACKET TO ENGINE
456
SCREW , Replaced By: N304017016004
456
SCREW , Replaced By: N000933016082
472
LOCK WASHERROCKINGER TYP 59 G140,59 G150
476
WASHER CONSOLE TO TRANSMISSION
480
SPACER TUBE BEARING BRACKET TO CYLINDER CRANKCASE,648356
480
SPACER TUBE BEARING BRACKET TO CYLINDER CRANKCASE
484
BRACKET BEARING TUBE
488
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
488
SCREW , Replaced By: N910105010009
488
SCREW REAR EXHAUST PIPE TO MUFFLER
488
SCREWM 10X20
488
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
488
SCREW END PIECE TO EXHAUST PIPE M 10X25
494
SCREWM 16X25
494
SCREW , Replaced By: N304017016011
504
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
507
NUT BRACKET TO SUPPORT AND TO END PIECE
510
NUT ,4 179002-4 369654
512
LOCK WASHERROCKINGER TYP 59 G140,59 G150
520
SPACER TUBE CLAMP TO BRACKET AND TO PIPE, TO BE ADAPTED DURING ASSEMBLY
520
SPACER TUBE BEARING BRACKET TO CYLINDER CRANKCASE
520
SPACER TUBE ENGINE SUPPORT TO TIMING CASE
538
SCREW BRACKET TO BELL HOUSING
538
SCREW , Replaced By: N304017008021
538
SCREW PIPE CLAMP
540
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
615
BRACKET
615
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 442 513557, Replaced By: A4420722340
615
BRACKET , Replaced By: A4420722840
615
BRACKET CYLINDER,734141
618
SCREW WIPER BEARING
618
SCREW CLAMP MOUNTING M 6X16
646
WASHER COMPRESSED AIR LINE TO BRACKET
646
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
646
WASHER COVERING TO CAB
876
CYLINDER , Replaced By: A0000723212
876
CYLINDER , Replaced By: A0000702183
876
CYLINDER , Replaced By: A0000702183
876
CYLINDER TORQUE REDUCER BOSCH
877
REPAIR KITTO 000 070 17 83
878
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
STOP INTERMEDIATE SPEED STOP
999
STOP INTERMEDIATE SPEED STOP
999
CYLINDER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 051317, Replaced By: A0000701583
999
CYLINDER , Replaced By: A0000701983, +001A4410721740, +001A4412230641
999
CYLINDER , Replaced By: A0000723212
999
REGULATING UNIT , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 258570/92, Replaced By: A0000720265
999
CYLINDER , Replaced By: A0000720612, +001A4030720574
999
CYLINDER , Replaced By: A0000720812
999
CYLINDER , Replaced By: A0004304826
999
CYLINDER , Replaced By: A0000721512
999
CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0000720512, +001A4420720624
999
CYLINDER , NOT USED
999
CYLINDER (OPERATING CYLINDER)
999
CYLINDER , Replaced By: A0004302326
999
CYLINDER (POWER CYLINDER)
999
CYLINDER , Replaced By: A0004304926
999
BUSHING , Replaced By: A0004340850
999
BALL SOCKET PULL ROD TO LEVER
999
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
999
TUBE GUIDE TUBE TO CYLINDER HEAD
999
LEVER
999
WASHER , Replaced By: N000988008006
999
BUSHING , Replaced By: A4039920001
999
SPACER TUBE , Replaced By: A6673170253
999
CYLINDER
999
CYLINDER , Replaced By: A0000720112
