Поз.
Артикул
Описание
11
PULLEY
18
SUPPORT ALTERNATOR
23
BUSHING
26
SCREW AUXILIARY FRAME MOUNTING
39
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
39
SCREW , Replaced By: N304017010035
45
SCREW BRACKET TO BELL HOUSING
46
NUT , Replaced By: N913023010002
46
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
47
WASHER RADIATOR TO RUBBER MOUNTING
48
CLAMP FUEL LINE, 741959
48
CLAMP FUEL LINE TO SUPPORT
49
SCREW , Replaced By: N000000001479
49
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
51
HEXAGON HEAD BOLT. SCREW THROTTLE HOUSING TO FRONT EXHAUST PIPE M 12X70
51
HEXAGON HEAD BOLT AIR DEHYDRATOR TO BRACKET M12X55,V 207570
60
NUT BRACKET TO SIDE MEMBER M12X1.5
61
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
61
WASHER , Replaced By: N000433013010
63
CLAMPING BOLT (CLAMPING BOLT)
69
CONNECTOR CLAMPING BOLT TO ALTERNATOR
72
NUT TENSIONING SCREW ON FIRST GENERATOR
73
NUT CLAMPING BOLT TO ALTERNATOR
75
SCREW CLAMPING BOLT TO ALTERNATOR
83
HEXAGON HEAD BOLT. SCREW VIBRATION ABSORBER TO BRACKET M 10X65
86
WASHER RADIATOR TO RUBBER MOUNTING
89
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
89
NUT , Replaced By: N913023010002
91
COVER WITH AIR INTAKE. COVER
92
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
92
NUT , Replaced By: N913023006001
999
BUSHING
999
CLAMPING BOLT
999
BUSHING , NOT USED
999
SPRING WASHER LICENSE PLATE TO BRACKET
