Поз.
Артикул
Описание
7
BRACKET , Replaced By: A4221300235
7
SUPPORT BRACKET TO COMPRESSOR BRACKET, TO BE ADAPTED DURING ASSEMBLY
14
SCREW SUPPORT TO CYLINDER CRANKCASE
21
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
28
BRACKET (CONSOLE),HYDRAULIC PUMP
28
BRACKET , Replaced By: A4222300240
35
SCREW BRACKET TO TRANSMISSION
35
SCREW , Replaced By: N304017010050
35
SCREW , Replaced By: N308676012038
35
SCREW , Replaced By: N304017010055
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
35
SCREW UNDERRUN PROTECTION AND BRACKET TO FRAME
35
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
42
WASHER STRUT TO CROSS MEMBER
42
WASHER , Replaced By: N007349010007
42
WASHER BRACKET TO SIDE MEMBER
49
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
49
COTTER PIN LEVER TO ROD
56
STIFFENING
56
STIFFENING , 229475
56
STIFFENING , Replaced By: A4222300394, +001A4442300008, +001N000439014206
63
BEARING BODY BRACING TO SUPPORT
70
BUSHING
77
NUT JOINT TO BRACKET
77
NUT , Replaced By: N308675014001
84
SCREW BRACKET TO FRAME SIDE MEMBER
91
BEARING BRACKET
91
BEARING BRACKET , Replaced By: A4222300039
98
BUSHING
98
BUSHING
105
SCREW
112
SCREW PIPE TO CHARGING AIR INTERCOOLER
114
NUT BRACKET TO SUPPORT AND TO END PIECE
116
SCREW , Replaced By: N304017010043
116
SCREW BRACKET TO CONSOLE
123
PULLEY TWO-GROOVE
123
PULLEY TWO-GROOVE
123
PULLEY CRANKSHAFT
130
STUD BOLT FAN TO CRANKSHAFT M 8X65
130
STUD BOLT P.T.O. CASE TO TRANSMISSION CASE M 8 X 65
137
NUT
144
STUD BOLT PULLEY TO VIBRATION ABSORBER
151
NUT
151
NUT , Replaced By: N304032008006
999
BUSHING
999
INTERMEDIATE PIECE FAN TO VIBRATION DAMPER
999
STIFFENING , Replaced By: A4032300194
999
STIFFENING , Replaced By: A4032300294, +001A4031504170, +001A4031504370, +001A4032300039
999
BRACKET , Replaced By: A4032300740
999
BRACKET ,617.024-15-229475, Replaced By: A4222300140, +001A4221300035, +001A4222300139, +001A4222300294
999
INTERMEDIATE PIECE , Replaced By: A4220350314, +006N000933008247
999
INTERMEDIATE PIECE , Replaced By: A4030350914
