Поз.
Артикул
Описание
5
ENGINE SUPPORT FRONT
8
SCREW
8
SCREW END PIECE TO EXHAUST PIPE M 12X30
11
LOCK WASHER FITTING TO BRACKET
14
SUSPENSION EYE FRONT
17
SUSPENSION EYE BRACKET TO ENGINE, TO BE ADAPTED DURING ASSEMBLY
20
SCREW FRONT SUSPENSION EYE TO CYLINDER CRANKCASE M 20X40
20
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
20
SCREW , Replaced By: N910105010009
20
SCREW , Replaced By: A0019908204
23
SCREW BRACKET WITH FUEL FILTER TO ENGINE
41
TYPE PLATE , STATE ENGINE NO.AND CHASSIS NO.WHEN ORDERING
41
TYPE PLATE , Replaced By: A3665842001
44
RIVET , Replaced By: A0039909597
44
RIVET ENGINE PLATE TO ENGINE
