Поз.
Артикул
Описание
5
OIL PAN
5
OIL PAN , Replaced By: A4420100613
12
THREADED INSERT
26
SCREW PLUG
33
SEAL RING OIL DRAIN 26X34 MM
54
SUCTION PIPE OIL SCAVENGING
57
SEAL RING
61
WASHER SUCTION PIPE TO OIL PAN
68
GASKET OIL PAN TO CYLINDER CRANKCASE
68
GASKET , Replaced By: A4420141122
68
GASKET , Replaced By: A4420141122
68
GASKET , Replaced By: A4420141122
75
SCREW BRACKET TO ENGINE
89
OIL FILLER NECK
117
GASKET OIL FILLER NECK
124
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
124
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
131
SPRING WASHER , Replaced By: N000137008212
131
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
152
OIL DIPSTICK
159
SEAL RING
166
CAP
173
GUIDE TUBE OIL DIPSTICK
173
GUIDE TUBE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 733625, Replaced By: A4420102466
999
PLASTIC PIPE. HOSE (VACUUM LINE) FROM ENGINE TO BRAKE BOOSTER 440 MM
999
GASKET , Replaced By: A4420140222
999
GASKET , Replaced By: A4420180080
999
FITTING OIL SCAVENGING
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
