Поз.
Артикул
Описание
164
CYLINDER (OPERATING CYLINDER)
164
CYLINDER (OPERATING CYLINDER)
164
CYLINDER (OPERATING CYLINDER),918799
164
CYLINDER INJECTION PUMP CONTROL
164
CYLINDER , Replaced By: A0000721512
164
CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 442 - 743376, Replaced By: A0000723112
165
ROD CYLINDER
165
ROD
165
ROD CYLINDER
165
ROD CYLINDER
168
BALL SOCKET
168
BALL SOCKET
168
BALL SOCKET
176
NUT AT SHIFT LEVER
176
NUT
176
NUT , Replaced By: N304035008001
184
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
334
PLATE
342
SCREW CLAMP TO BATTERY CASE
350
SCREW
358
BRACKET OPERATING CYLINDER TO BRACKET
366
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
366
SCREW , Replaced By: N304017008034
366
SCREW BRACKET TO CROSS CONNECTION STRUT
374
WASHER , Replaced By: N000125008443
374
WASHER EXHAUST MUFFLER TO STRAP
380
BALL PIVOT
384
SEAL RING MODULATION PRESSURE CONTROL
388
SCREW MINOR QUANTITY STOP
396
NUT SPRING-LOADED PUSH ROD
400
BALL PIVOT
404
SEAL RING MODULATION PRESSURE CONTROL
999
CYLINDER (POWER CYLINDER)
999
SPACER RING MANUAL FINE CONTROL TO GOVERNOR HOUSING
999
ROD END
999
LEVER (DOUBLE LEVER)
999
THREADED UNION CYLINDER TO LEVER
999
SPACER TUBE CYLINDER TO LEVER, NOT USED
999
BUSHING
999
SCREW INJECTION PUMP WITH DRIVE GEAR TO CRANKCASE, NOT USED
999
SCREW BRACKET TO INJECTION PUMP,012077 NOT USED
999
SPRING , Replaced By: A4429935010
999
SCREW BRACKET TO INJECTION PUMP
999
COTTER PIN
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER SHIFTING CYLINDER TO CASE
999
PIN POWER CYLINDER TO BRACKET
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET
999
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
