Поз.
Артикул
Описание
5
PITMAN ARM ,007238
5
PITMAN ARM ,007238
5
PITMAN ARM ,007239
5
PITMAN ARM ,007239
8
NUT DRAG LINK TO LEVER
11
DRAG LINK ,007239
11
DRAG LINK , Replaced By: A4604635515
11
DRAG LINK ,007239
11
DRAG LINK ,007239
11
DRAG LINK ,007238
11
DRAG LINK ,007238
11
DRAG LINK ,007239
11
DRAG LINK ,007238
14
JOINTTO 463 463 03 15,463 463 06 15
14
BALL JOINTTO 460 463 51 15,463 460 01 05
14
JOINT , Replaced By: A0003308535
14
BALL JOINT , Replaced By: A0003300635
14
JOINT R.H. THREAD LEMFOERDER
17
BOOTLEMFOERDER
17
BOOT , Replaced By: A0003300985
17
BOOT , Replaced By: A0004631796
17
BOOT
20
CLAMP
20
CLAMP BALL JOINT TO TIE ROD
20
CLAMPTO 463 463 03 15,463 463 06 15
23
CLAMPING PIECETO 463 460 01 05,463 460 02 05
26
SCREW
29
HEXAGON NUT
29
NUT , Replaced By: N910113010002
32
NUT , Replaced By: N000979016008
32
NUT LEVER
35
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
38
NUT SPRING SHACKLE TO SPRING REAR BRACKET
41
COTTER PINROCKINGER TYP 260 G140
44
NUT SHOCK ABSORBER TO CROSS MEMBER
44
NUT , Replaced By: N000979016007
47
COTTER PIN STRAP TO SUPPORT
50
SCREW STEERING TO FRAME M 12X1.5X155
53
WASHER
56
NUT , Replaced By: N910113012003
56
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
