Поз.
Артикул
Описание
1
BRACKET , UP TO IDENT NO. 693528 EXCEPT FOR 500001-599999
2
GUIDE BRAKE PEDAL THRU CAB FLOOR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 589554
4
SHIM BRACKET TO CAB FLOOR, 309.300-320,400-420 UP TO CHASSIS 043826, 309.370-380 UP TO CHASSIS 004062, 310.300-399 UP TO CHASSIS 003708
4
SHIM BRACKET TO CAB FLOOR, 309.300-320,400-420 FROM CHASSIS 043827, 309.370-380 FROM CHASSIS 004063,310.300-399 FROM CHASSIS 003709
6
BRACKET MASTER CYLINDER
7
RIVETED NUT , Replaced By: N913010006106
7
RIVETED NUT REFRIGERANT LINE TO CAB REAR PANEL
10
LEVERI
10
LEVER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 589670, Replaced By: A3104301123
11
PIN LEVER I, NO LONGER AVAILABLE INDIVIDUALLY
14
BALL PIVOT LEVER
14
BALL PIVOT , Replaced By: A3129910120
15
YOKE OPERATING ROD
17
SPRING WASHER SHIFTING CYLINDER TO YOKE
18
PIN
19
WASHER , 034 UP TO CHASSIS A 004589
22
SPRING , 309.300-326 UNTIL PRODUCTION STOP 309.370-391 UP TO CHASSIS 014221,309.400-426 UP TO CHASSIS 095115,310.300-326,400-426 UP TO CHASSIS 019232 FROM CHASSIS SEE STANDARDVERSION
23
BRACKET LEVER I, 309.300-320,400-420 UP TO CHASSIS 043826, 309.370-380 UP TO CHASSIS 004062, 310.300-399 UP TO CHASSIS 003708
25
FITTED WASHER
26
LOCK RINGTO 000 553 37 01,000 553 39 01,
29
BRAKE PEDAL
31
PAD , 016,017,018 UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999 UP TO IDENT NO. 4 667210,FROM IDENT NO.SEE SA 25011
32
BRACKET LEVER II
37
LEVERII
38
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
38
BALL PIVOT ACCELERATOR PEDAL,4 859026
38
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
39
SPRING WASHER PULL ROD TO LEVER II
40
NUT BALL PIVOT TO LEVER
43
ROD FROM LEVER I TO LEVER II
45
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
46
NUT BALL PIVOT TO LEVER
47
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
49
PULL ROD
50
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
52
NUT BALL PIVOT TO LEVER
53
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
RIVETED NUT , Replaced By: N913010006106
999
BRAKE PEDAL , Replaced By: A3094300018
999
ROD , Replaced By: A3104300692
999
ROD , Replaced By: A3104300692
999
COTTER PIN
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017008034
999
NUT
999
SCREW
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
