Поз.
Артикул
Описание
5
EXHAUST PIPE FRONT, FROM CHASSIS 135949-246155 EXCEPT FOR,SEE FOOTN.3
14
GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
17
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
20
NUT CONNECTOR TO EXHAUST MANIFOLD
23
CLAMP EXHAUST PIPE TO MUFFLER
23
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
26
SCREW , Replaced By: N304017008043
26
SCREW , Replaced By: N304014008001
26
SCREW REAR AXLE REGULATING SOLENOID VALVE
26
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
26
SCREW VALVE TO BRACKET M 8X55
29
WASHER BRACKET TO CROSS MEMBER
32
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
35
NUT
41
REAR EXHAUST PIPE FRONT PART,245341
47
EXHAUST PIPE REAR,REAR PART,245341
56
EXHAUST MUFFLER
62
BRACKET , Replaced By: A3184923441
62
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
68
BRACKET EXHAUST MUFFLER SUSPENSION
80
SUSPENSION PROTECTIVE PLATE TO EXHAUST PIPE
83
SCREWM 8X40
83
SCREW VALVE TO BRACKET
86
WASHER , Replaced By: N000125008443
86
WASHER EXHAUST MUFFLER TO STRAP
89
NUT
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
89
NUT , Replaced By: N913004008001
92
SUPPORT EXHAUST MUFFLER, 10/50 310.400-403,411 UP TO IDENT NO.245341, 20/60 310.400-403,411-426 UP TO IDENT NO. 246155, 310.404,405,417 UP TO IDENT NO. 246272
95
SUPPORT REAR EXHAUST PIPE
98
SCREW END PIECE TO EXHAUST PIPE M 10X25
101
SCREW BRACKET TO CROSS CONNECTION STRUT
101
SCREW , Replaced By: N304017008034
104
NUT AIR CLEANER ELEMENT
107
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
NUT , Replaced By: N913004008001
113
SUPPORT EXHAUST MUFFLER TO SIDE MEMBER, FROM CHASSIS 556500 ALSO INSTALLED ON 553210,556146
122
BRACKET REAR EXHAUST PIPE, 10/50 310.300-303,311-326,20/60 310.300-303,311-326,UP TO IDENT NO. 246155,310.304,305,327 UP TO IDENT NO. 246272
128
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
131
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
134
NUT BRACKET TO SUPPORT AND TO END PIECE
158
CLAMP EXHAUST PIPE TO MUFFLER
167
PROTECTIVE PLATE REAR EXHAUST PIPE TO BRACKET AT SHOCK ABSORBER CROSS MEMBER
170
RUBBER BUFFER BRACKET TO SUPPORT
173
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
176
SCREW VALVE TO BRACKET
176
SCREW REAR AXLE REGULATING SOLENOID VALVE
176
SCREW VALVE TO BRACKET, Replaced By: N304014008002
182
WASHER , Replaced By: N000125008443
182
WASHER EXHAUST MUFFLER TO STRAP
188
NUT BRACKET TO FRAME M 10X1
188
NUT AIR CLEANER ELEMENT
188
NUT , Replaced By: A1201420072
188
NUT , Replaced By: N910113010004
188
HEXAGON NUT SCREENING PLATE,5 163561
999
RUBBER BUFFER EXHAUST MUFFLER
999
NUT EXHAUST PIPE TO EXHAUST MANIFOLD
999
NUT , Replaced By: N913004008007
999
NUT , Replaced By: N913004010000
999
CLAMP , Replaced By: A1074900041
999
CLAMP , Replaced By: A1074920340
999
CLAMP , Replaced By: A1074900141
999
CLAMP , Replaced By: A1074920340
999
INSULATING WASHER. INSULATION , Replaced By: A3094900037
999
CLAMPING PLATE. BASE PLATE FRONT EXHAUST PIPE,B 884219
999
RUBBER DAMPING PLATE. DAMPING PAD , Replaced By: A3095860049
999
SPACER TUBE FRONT EXHAUST PIPE,B 884219
999
FLANGE GASKET , Replaced By: N917003060003
999
BRACKET CLAMP TO CROSS MEMBER,245341
999
REPAIR KIT , Replaced By: A3094900037
999
EXHAUST MUFFLER , Replaced By: A3144900501, +001A3184910041
